GCJ02-50-I/II BH Weighing Type Automatic Liquid Filling Machine
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
GCJ04-06-IAQ Weighing Type Automatic Liquid Filler
-
GCJ-02-06-I/IIBG Weighing Automatic Liquid Filling Machine
-
GCJ-02-06-I/IIBLG Weighing Automatic Liquid Filling Machine
-
GCJ02-50-IBR Weighig Automatic Liquid Filling Machine
-
GCJ02-50-I/II BH Small Opening Barrels Liquid Filling Machine
-
GCJ04-06-IIBQF Square Barrel Weighing Filling Machine
Product Details
| Condition | New | Application | Food, Chemical | |
| Packaging Type | Cartons | Packaging Material | Wood, Other, Wood, international sea freight package | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 380V | Power | 50HZ | |
| Place of Origin | Jiangsu, China | Brand Name | SAILING | |
| Model Number | GCJ02-50-I/IIBH | Dimension(L*W*H) | 2255X800X1430 | |
| Certification | ISO CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
weighing type automatic liquid filler , round and square barrels, with small opening can be adapted
Main features:
This filling machine is suitable for the filling of small-opening barrels within 50 kg.
This machine is able to adapt to round and square barrels. It’s equipped with double heads cap pressing machine.
Suitable material:
Coating, paint, ink, glue, curing agent, solvent, chemicals, detergent, pestiside, medicine, lubrication oil and all kinds of flowing liquid.
.
Product standards: Q/320281ATB02-2013
Main functions:
1.Manual barrels positioning, automatic double heads filling.
2.Barrels are pushed forward by motor, it is equipped with double cap pressing mechanism
3.Barrels positioning and cap placing can be done by one operator.
4.Round and square barrels, with small opening can be adapted.
5.I is the hopper type, II is top filling type filling head.
6.The filling head of filling machine can enter into the barrel before filling, when the filling head is not in the right position, it will return automaticlly.
7.Double heads filling and single head filling choosable
8.Automatic alarm when filling error exceed setting limit.
9.A is normal model, B is explosion proof model.
10.Explosion proof grade: EXD IIBT6.
11.The machine has the common fuctions of weighing type filling machine.
Main Technical Parameter
Filling Scope | <50kg | Filling Speed | 6-8can/min |
Filling Head | 2 | Size of Can | ≤Φ180*h200 |
Error Value | ±10g | Explosion-proof Grade | EXDIIBT6 |
Division value | 5g | Air | 0.5Mpa |
liquid filler,automatic liquid filler,liquid packing machine,weighing type filler
TESTING REPORT | YES. Always provide official test report before delivery. | ||||
OEM SERVICE | YES | ||||
CERTIFICATE | BV PRODUCT CERTIFICATE. CE | ||||
COLOR | WHITE, BLUE OR OPTIONAL | ||||
PRICE | |||||
PAYMENT | T/T, L/C, | ||||
PORT | SHANGHAI, SHENZHEN,GUANGZHOU | ||||
MOQ | 800SETS/YEAR | ||||
DELIVERY TIME | 15DAYS FOR STANDARD MACHINE | ||||
NOTE | |||||
We will offer you price referring to your detail request, so please kindly inform us of the material, viscosity, density, etc, and other requirements you prefer, and the special offer will be given. The pictures are above just for your reference. | |||||
