Automatic Continuous PU Foaming Production Line Quality Choice
- SHENZHEN
 - T/T L/C D/P D/A Credit Card PayPal

You May Like
-


Automatic Continuous Low Density Foam Sponge Making Machine
 -


Horizontal Continuous Polyurethane Foam Making Machine
 -


QH Dongguan Low Pressure Polyurethane Foam Machine
 -


QHFP-11/15A Horizontal Manul Foaming Macking Machine
 -


Horizontal Continuous Polyurethane Sponge Foam Making Machine
 -


PLC Control Semi-automatic Foaming Machine

Product Details
| Product Type | Other, Horizontal Automatic Foaming Machine | Place of Origin | Guangdong, China | |
| Brand Name | QHMACH | Model Number | QHF-2015 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
[Specifications]
This machine is mostly used to produce large-scale continuous foaming production (density is about 6 to 100 kg/m3 ). It adopts the advanced touch screen and PLC Operation System, its automatization level is high, the production is low-cost and the quality of foam is outstanding.
Main technique specifications
1.Total length 33m×total width 4m×total height 3m (From the mixing head to the cutting machine )
2.Foaming width : 980mm~2250mm
3.Foaming height : Max 1200 mm
4.Foaming density : 8kg/m3~100kg/m3
5.Foaming speed : 2000r/min ~ 7000r/min
6.Max total output : 300kg/min
7.Mixing head motor : 37KW
8.Total power : About 100kw
9.Material spraying way :
The way of down sprayer head (upper, down, front and back can be adjusted )
The way of trough
10.Oven declining board : L9m×W0.98m~2.30m
| Motor | Guangdong brand |
| Pump | Viking pump & Chinese pump |
| Invertor | Siemens brand |
| PLC | Siemens |
| Temperature | Control system |
Remark: The above only for reference. All the data is subjected to the sold production.
Material tanks,connecting pipe and pumps
Block cutter
Dongguan Qianghui Machinery Co., Ltd is specialized in research and development and manufacture foam machines. Take the advance technology of some profession and improvement. Absorb the new originality strictly control the product quality full service tracking insist on manufacturing the high quality products.
How is the packing of the machine?
The entire machine will be nude packing. Some of the parts will be pack in wooden case. Others will be simple pack with paper or foam sheet with plastic film.
How many container will be needed for the whole set of machine?
Total three containers is enough 2*40HQ+1*20GP. In order to save the place and the cost of delivery we will also put some parts that inside the raw material tank.
We will try the best way to pack all the machine well and also save the freight cost.
We will help to design the layout of the machine that put in your factory.
We will send 2-4 experience engineers to install and testing the machines.
We will teach your engineer how to operate the machine and how to maintain the machines.
We will give you the machine operation manual and the best formulation for target products that you are going to make.
Q: How many days for the install and testing of the machine?
A: After all the machine in your factory we will send 1-2 engineer help to install the machine you must send someone to help about 30 days installation will finished. After that one electrician and one foaming engineer will come to connecting the cable and run the machine in 15days. Total 45days the machine can be running.
Q: For the cost of the engineer how much I need to pay?
A: You need to pay USD50 one day for one engineer and also need to pay for the visa fee turn-round ticket fee and food hotel.
Q:What kind of raw material tools we need to prepare for the testing?
A: We will send you a list for the tools that you need to prepare for testing and also can help to buy if you required.
Q: After the machine testing if we need some engineer to stay in our factory can you help to find?
A: Sure we can help to hire one experience engineer to work in your factory but you need to discuss the salary and all details with him.
Q:During the foaming if we have some problems abt the foam and the machine how can we do?
A: You can just call our after sale manager explain for the situation or send some picture we will help to handle within 24hours.

Welcome to contact us and negotiate business with us. We sincerely hope to cooperate with your company!
