Home > Products > LED Controller&Power Supply > Best seller DC12V LED RGB Amplifier/RGB LED amplifer/driver RGB Amplifer

Best seller DC12V LED RGB Amplifier/RGB LED amplifer/driver RGB Amplifer

FOB Price

USD $1 - $2 / Piece

50 Pieces(Min.Order)

Supply Ability 50000 Piece / Pieces per Month
Port Shenzhen
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	simonlighter
Model Number	SML-Amplifier-B	Type	Remote Control
Max. Load Power	5V:<60W, 12V:<144W, 24V:<288W, 5V:<60W, 12V:<144W, 24V:<288W	Voltage	Other, DC12V/24V

Product Description

Best seller DC12V LED RGB Amplifier

DC12V RGB LED Amplifier
1,Voltage:12V-24V
2,Output:3 ch*10A =30A 360W
3.2 years warranty

This RGB amplifier is suitable for all kinds of constant voltage led RGB controller. it can enlarge the led controller single through the RGB to receive the PWM(pulse width modulation),and output the single to the load ,then it can make the same effect with the controller.when add each additional amplifier, can connect and controlled twice more LED lights.theoretically , one controller can connector with thousands of this RGB amplifier, and can make the same effect.

Specifications:

Working temperature	-20-60°C
Input voltage	DC12~24V
Output	3 circuit
Connection mode	Common anode
product’s size	L113×W65×H24mm
package size	L117×W72×H64mm
Net weight	100g
Gross weight	125g
Static power consumption	<1W
Output current	4A/CH*3CH=12A
Output power	12V: <144W;24V: <288W

Size:

Connection description:

1.Power input interface:

Adopt the 5.5*2.1mm DC plug connector

2.Signal input interface:

Adopt clamp connector,easy for connection

3 .Load output interface:

Adopt clamp connector,easy for connection

Direction for use:

Connect the input and output wire in sequence according to the specification one the label of the amplifier, make sure that no short circuit phenomenon,then connect the amplifier to the DC12V/24V power supply , and used with the led light , the wiring diagram are as follows:

application circuit 1:

Application circuit 2:

Cautions:

1,This products Input voltage is DC12-24V,other input voltage are not allowed.

2,Lead wire should be connected correctly,according to the wire color and the connecting diagram offers.

3,Overload are prohibited.i
