Hot rf remote control 1 channel dimmer/12v automatic led infrared zigbee wireless dimmer switch

FOB Price

USD $1 - $2 / Piece

50 Pieces(Min.Order)

Supply Ability 50000 Piece / Pieces per Month
Port Shenzhen
Payment TermsT/T D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	simonlighter
Model Number	SML-DIMW-C	Type	Remote Control
Max. Load Power	384W	Voltage	Other, DC5V, 12V~24V optional (specify the required voltage on orders)

Product Description

Hot RF remote control 1 channel dimmer

This led dimmer used to control a variety of led lamps as the light source, For example, point source of light, flexible light strip, wall washer lamp, glass curtain wall light and so on; With competitive price, easy wiring, simple to use etc.; Through the infrared remote control and dimmers on the knob to adjust brightness; Gray level 255; with custom features, With 30 seconds delay OFF function and a fixed gray scale output.

External Dimension

Technical Parameters

Working temperature	-20-60°C
Supply voltage	DC5V, 12V~24V optional (specify the required voltage on orders)
0utput	1 channel
External dimension	L87W87H53 mm
Packing size	L106xW106xH66mm
Net weight	150g
Gross weight	200g
Static power consumption	<1W
Output current	8A or 16A each channal optional
Output power	8A: 5V<40W; 12V < 96W; 24V<192W 16A: 5V<80W;12V < 192W;24V<384W

Direction for use

Connect the load wire at first, following by the power wire; Please ensure short circuit can not occur between connecting wire before you turn on the power;

When operation, the remote control facing the infrared receiver, ensure that there are no obstructions between remote controller and receiver; When dimmer receives an effective signal from the infrared remote control, the red light on the upside flickers; There are two methods in Dimming:

(1).Infrared remote control adjustment mode; the 12 key features as follow(range as the keys of remote controller)

Typical Application Circuit:
