2014 Newest And Strongest Error Free Pro Canbus Hid Ballast AC 55W

Specifications



 Introduction:

1. This is our 2014 newest 55W CANBUS HID ballasts, it's China best CANBUS HID ballast;Strong and nice;
2. We already test this ballasts on Porsche, BMW, Golf, Audi, Mercedes, Mini, VW, Volv, Fiat, Citroen, Ford, Opel, Renault, Seat...They work perfectly well on the above list cars with NO error code; Our customer said this new canbus ballast is really strong;
3. We provide with two year warranty for this ballast.

Specification:

Unit size: 85X65X17MM

1) Input voltage: 9~16V AC;
2) Max start current:  ≤4.5A/13.5V;
3) Steady current: 13.5V 4.4A;
4) output power: 55W±1W;
5) Instant start voltage: 23000V±2000V;
6) Output voltage: AC85±17V, can work under the tube voltage 60~150V;
7) Operation temperature:-40°C~105°C
8) Efficiency:85~87%;
9) Frequency: 250±30HZ;
10) Waveform: square wave;
11) Lifespan: >3000 hours;
12) EMC: S95/54/EC;
13) Open circuit protection: within 1 second;
14) Short circuit protection: within 1 second;
15) Reverse voltage protection
16) Waterproof, dustproof and shockproof

Compatible with:
H series: H1,H3,  H3C,H4-1,H4-2,H7,H7C,H7R,H8,H9,H10,H11,H13,H13-2
9 Series:9004,9004-2,9005,9006,9007-2
D Series: D1S,D2S,D2C,D2R
Moving Series:H4-3,H13-3,9004-3
Double Lamp Series:H4-2 H13-2 9004-2 9007-2

Compatible with:
H series: H1,H3,  H3C,H4-1,H4-2,H7,H7C,H7R,H8,H9,H10,H11,H13,H13-2
9 Series:9004,9004-2,9005,9006,9007-2
D Series: D1S,D2S,D2C,D2R
Moving Series:H4-3,H13-3,9004-3
Double Lamp Series:H4-2 H13-2 9004-2 9007-2

Application:

1) fog light

2) headlight

Our HID lamps:

Brief Diagram of HID Installation:
