High Quality &Certificated with CE/ISO9001-2008 table concentrator
- 200 Set / Sets per Month
- Qingdao
- T/T
You May Like
-
High Quality &Certificated with CE/ISO9001-2008 mineral shaker
-
High Quality &Certificated with CE/ISO9001-2008 Shaking Table
-
Portable ball mill for sale at good price with ISO 9001
-
Henan Hongji ball grinding mill with ISO 9001 CE and large capacity
-
SF flotation machine for mineral separation
-
ceramic sand production line with ISO9001:2008 certificate
Product Details
Condition | New | Type | Gravity Separator | |
Production Capacity | high | Place of Origin | Henan, China | |
Brand Name | HONGJI | Model Number | L-S | |
Voltage | 220v | Power(W) | 1.1kw | |
Dimension(L*W*H) | 5454*1825*1242 | Weight | 1012kg | |
Certification | CE, ISO | Warranty | one year | |
After-sales Service Provided | Engineers available to service machinery overseas |
International standand packing or based on customer requirements
Product Description
Specifications
table concentrator:1,low investment , high efficiency
2,easy maintence
3,widely used
High Quality &Certificated CE/ISO9001-2008 table concentrator
Application:
it is widely used for separating ore particle and slime with size 2-0.02 mm, such as tin,
tungsten, gold, silver, lead, zinc, tantalum, niobium, iron, manganese, ilmenite, coal and so on.
Working principle:
The motor drives the eccentric shafts to rotate and the connecting rod to move up and down. With the rod moving down, minerals on tilting deck installed by rifle spokes go into the feed box. At the same time, water stored in the water tank impacts the minerals laterally.
Main technical parameters:
Model | L-S (6-S)type | Clean water(t/h) | 0.4-0.8 |
Stroke(mm) | 10-30 | Table size (mm) | 1520*1825*4500 |
Frequency(time/min) | 240-360 | Motor(kw) | 1.1 |
Horizontal obliquity(o) | 0-8 | Capacity(t/h) | 0.5-1.2 |
Sorting size(mm) | 2-0.074 | Weight (kg) | 1012 |
Feeding thickness(%) | 15-30 | Dimension(mm) | 5454*1825*1242 |
Flow chart of the benefication process and machine needed :
Quotation will be early sent to you if ur enquiry provide :
1, What is the result of your ore composition analysis ? what is your requirement of the final products?
2, What machine you want to buy? shaking table or a whole line plant?
3, What is your capacity?
4, What is the raw material ore size?
work site:
support:
Comapny certification and honor:
Our customers from different countries:
Company Profile

Henan Hongji Mining Machinery Co., Ltd. is a reputed manufacturer and joint-stock enterprise with import & export rights and mainly produces large and medium-sized mining machinery, metallurgy machinery and building material equipment. Our headquarters, covering 80,000 square meters, is located in Mechanical Industrial Park of West Zhongyuan Road, Zhengzhou City, Henan Province, China, owning more than 180 sets of heavy processing equipment with an annul output of more than 800 sets of mining machinery. Our fixed asset is RMB80,000,000 and we have four subsidiaries and a R&D department. Since the establishment, we have been insisting on the scientific management system of modern enterprise, manufacturing with care and creating independently. Lots of technological elites assemble here. There are more than 880 employees, including 138 middle and senior engineers and more than 200 skilled workers in our company. We have been cooperating with domestic and foreign Scientific Research Institutes for a long time and have set up a testing base which has domestic and foreign techniques. Product quality is considered as the life of our company and all our products have attained the certification of ISO9001:2000 qualify system. Moreover, superior after-sales services guarantee high quality continuously. In addition, we have a group of experienced and excellent after-sales service members who provide following up services for worldwide customers. Customers' need is what we are trying to create. Customer satisfaction is what we are seeking. Over the last couple of decades, Hongji people have created continuously, transcending ourselves and insisting on the concept of "Development is of overriding importance". Develop the brand with quality. Promote the brand with service. We, Hongji people, are forging ahead for first-class brand with innovative spirit and do our best to contribute to the national industry.
