High effective and good quality 260W Mono solar panel, Monocrystalline PV panel

100W Monocrystalline Solar Panel

(Values at Standard Test ConditionsAM1.5   Irradiance:1000W/ m² T:25°C)

ITEM NO.

 S/M-100

Maximum Power at ST(Pmax)W

100Wp

Maximum Power Voltage(Vmp)V

18

Maximum Power Current(Imp)A

5.55

Open Circuit Voltage(Voc)V

19.05

Short Circuit Current(Isc)A

6.09

Cell Efficiency(%)

18.6%

Module Efficiency(%)

17.4%

Silicon Type

Mono

Series Fuse Rating (A)

12

Brand Name of Solar Cells

top brand Cell

Size of Module (mm)

1000*665*35mm

Solar Cell

125*125Mono

Number of Cell (PCS)

36(4*9) cells

Weight (KG)

23

Power Tolerance

0~+3%

Components & Mechanical Data

Front Glass Thickness (mm)

High Transparency Tempered Glass 3.2mm

Junction Box Type

Pass the TUV Certificate PPO(Black/IP65)

Output Cables

4mm²/0.9m

Frame (Material Corners, etc.)

Aluminum-alloy

Encapsulation Material

EVA(0.50±0.03 mm thickness)

Back Foil

White TPT(0.32±0.03 mm thickness)

Fixing Adhesive

Silicone Sealant ( White)

Temperature Range (°C)

-40°C to +90°C

Max Load Capacity(Kpa)

2.4wind load/5.4 snow load

Temperature Coefficients

NOCT(°C)

47±2

Temperature Coefficient of Pm

-0.45±0.05 %/°C

Temperature Coefficient of Isc

0.05±0.01 %/°C

Temperature Coefficient of Voc

-0.35±0.02%/°C

Packaging:

1*20'GP

   420pcs / 20pallets

1*40'GP

890pcs /44allets
