      Feature

1. 1. Integrated solar street light use green energy, high-efficiency solar panel, LED light source and solar battery, all are new energy, environmental friendly.
2. 2. It uses microelectronic control, smart microwave sensors and other excellent practical control technology, combined with simple integration of structural design, low power consumption, high brightness. (5w equal to 100w incandescent bulb).
3. 3. Long life, free maintenance, waterproof, excellent performance on heat dissipation.
4. 4. Light weight, not too much wire connection work, very easy to install.
5. 5. Based on microwave sensor function, it can control the street light in different periods, the normal time+sensor+morning light design. Working time 0 to 15 hours, and power from 0 to 100% can be set
6. 6. Built-in rechargeable lithium battery, low temperature protection. When the ambient temperature is below zero, it can stop charge to protect the battery.
7. 7. Intelligent power mode, can automatically adjusts power according to the load of battery power, maximizing battery running time.
8. 8. The digital precision constant current control, the maximum efficiency up to 96%.
9. 9. The system of state records, can record up to seven days, monitor the system completely.
10. 10. Metal housing, IP65 waterproof rating (LED light source), can be used in a variety of harsh environment.
11. 11. Overheat protection, it will reduce or off the load when temperature is too high.
12. 12. The reverse battery protection, LED short circuit protection, open circuit protection, full protect the whole system.

      Model

Pole

A(MAX)

B(MAX)

C(MAX)

D(MAX)

SM-R021/10(10W)

SC-R021/10(10W)

Ø48-60mm

563

100

320

463

SM-R021/20(20W)

SC-R021/20(20W)

Ø48-60mm

975

153

275

825

Power

10W

20W

Model

SM-R021/10

SC-R021/10

SM-R021/20

SC-R021/20

Solar panel

18V-35W, high efficiency,

Imported mono solar cells

458*315*3mm

18V-40W high efficiency,

Imported mono solar cells

820*270*3mm

Battery type

(Iron phosphate)lithium battery 12V 12Ah

(Iron phosphate)lithium battery 12V 24Ah

Voltage

12-24V

LED type

   SMD5730

   0.5W/pc,

   EPISTAR

  Straw hat type lamp bead      0  0.06W/pc , Bridgelux

SMD5730

0.5W/pc,

EPISTAR

Straw hat type lamp bead

0.06W/pc. Bridgelux

Working time

10-12 hours         3-7 raining days

  LED number

24(8pcs in string, 3 strings in parallel)

144(8pcs in string, 18 strings in parallel)

48(8pcs in string, 6 strings in parallel)

288(8pcs in string, 36 strings in parallel)

LED Luminous flux

1200lm

      1380lm

2400lm

     2760lm

Luminous flux

1000lm(6500K)

1200lm(6500K)

2000l(6500K)

2400lm(6500K)

Installation height

3-4m

5-6m

Max. radar sensor distance

8M

8M

Installation  space recommend

8-10m

15-20m

Color temperature

3000K/4000K/5000K/6500K (optional)

Operating

temperature

-10℃~45℃

Color Rendering Index

Ra>70

      Designed life

50000H

Model

Packing size

N.W

G.W

Packing way

SM-R021/10

SC-R021/10

700*450*200mm

6.3KG

8.0KG

1PCS/carton

SM-R021/20

SC-R021/10

1150*400*250mm

10.1KG

11.8KG

1PCS/carton
