Aluminum Food Dishes Production Press Line

Aluminum food dishes production press line

Aluminum foil container production line CTJF-60T has been designed and developed as an upgraded model to produce aluminum food containers, dishes and trays. The working speed of machine CTJF-60T is 50-75 pcs/min (with one cavity mould), and its speed depends on container’s size and complexity. It can be equipped with multi- cavity moulds. Aluminum foil container production line CTJF-60T is composed of the followings: Decoiler (with an auto-lubricator) Electrical control panel Air output control equipment 60 ton pneumatic press Mould Auto-stacker or conveyor (including scrap collector) Collection desk.

Main Features:

(1) This production line can work automatically. Worker control and regulate this production line through electric control equipment.

(2) The width of decoiler is about 550mm.

(3) The feeding system control feeding length and stepping by computer, whicwhich assure a high-precision steps.

(4) We can design and manufacture different machines on request. There is some difference in machine’s outer-appearance.

(5) The press may be equipped with single cavity or multi-cavity moulds for wrinkle-wall or smooth-wall container production. The working flow of aluminum foil machine CTJF-60T: Aluminum foil roll ---decoiler---air output control equipment---60T pneumatic press---mould---auto-stacker or conveyor--- collection desk.

Components of production line:

1. Auto-lubricated Foil Feeder

2. Length Controller

3. Seimens Control Panel

4. Pneumatic Press

5. Automatic Stacker

1. Engineers available to service machinery overseas.

2. We can provide intermship service and help you to train

operator and machine.

3. CHOCTAEK offers a constant technical assistance to support the user, taking care of installation phases, tests and continuous maintenance assistance of the machines.

Since 2003,CHOCTAEK has been specialized in producing aluminum foil container mould, aluminum foil container production lines and other relatives machines. We are keep researching and developing machines and moulds to fulfill the integration and full-automation of aluminum foil container production. Till March on 2013, we have developed and produced 600 aluminum foil container moulds which are in different sizes and shapes.

We have exported machines and moulds to more than 30 countries and offer service to 80 companies. We continuously offer technical support and consulting service to new customers.

CHOCTAEK always pay attention on your requirement and concern your company's development. We make every effort to improve our technology & quality, to ensure to offer you product in best quality and technical service. We requite your expectation and support in the way of upgrading technology continuously. CHOCTAEK will satisfy your specific demand.
