Eco-friendly and Vertial Wood Fired Thermal Oil Heater/thermal oil boiler

FOB Price

US$ 3,000 - 10,000 / Set

1 Set(Min. Order)

Port qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other
Place of Origin	Shandong, China	Brand Name	ruifeng
Dimension(LWH)	customize	Weight	customize
Certification	iso9001.ce	Warranty	1years
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

The Parameter Table of Horizontal Wood Fired Thermal Oil Heater/Boiler

YLL-MA Series Vertical Fixed Grate Thermal Oil Boiler
Model	YLL-120MA	YLL-240MA	YLL-350MA	YLL-500MA	YLL-700MA	YLL-1000Ma	YLL-1200MA	YLL-1400MA	YLL-2000MA
Rated Thermal Power	120	240	350	500	700	1000	1200	1400	2000
Thermal Efficiency	≥70%	≥71%	≥72%	≥73%	≥74%	≥75%	≥76%	≥77%	≥78%
Working Pressure	1.1	1.1	1.1	1.1	1.1	1.1	1.1	1.1	1.1
Medium Temperature	340°	340°	340°	340°	340°	340°	340°	340°	340°
Circulating Oil Capacity	12.5m3/h	20m3/h	30m3/h	40m3/h	60m3/h	80m3/h	100m3/h	100m3/h	100m3/h
Mouthpiece DN	50mm	50mm	65mm	65mm	100mm	100mm	125mm	125mm	150mm
System Power	6.7KW	10KW	14.1KW	14.1KW	23.5KW	29KW	40KW	40.7KW	48.7KW
Fuel	Coal, Oil, Gas, Biomass
Fuel Consumption	28kg/h	56kg/h	80kg/h	100kg/h	155kg/h	185kg/h	240kg/h	290kg/h	400kg/h
Diameter	1150mm	1300mm	1700mm	1700mm	1960mm	2050mm	2106mm	2290mm	2620mm
Height	2385mm	2650mm	3060mm	3475mm	3805mm	4415mm	4760mm	5445mm	6430mm
Total Weight	2960kg	3225kg	3635kg	4050kg	4495kg	5105kg	5365kg	6045kg	9018kg
Working Medium	Thermal Oil
Oil Capacity of Ther Furnace	0.15m3	0.3m3	0.5m3	0.7m3	0.8m3	1.3m3	1.5m3	1.9m3	3.5m3

Company Information

Linyi Ruifeng Machinery Factory, founded in 1993, is one of the largest wood-based panel machinery manufacturers in China. Our products sell well in all cities and provinces around China, and are also exported to over 20 countries and regions, such as Russia, South Asia, Southeast Asia, Africa, etc. We also welcome OEM and ODM orders.

With well-equipped facilities and excellent quality control, we are engaged in producing plywood equipment, particleboard equipment, MDF equipment, short-cycle laminating equipment, block board equipment and other wood-based panel machinery. Moreover, we can produce hot press, pre-press, forming machine, edge trim saw, glue spreader and other woodworking machines according to customers' requirement.

Our general manager Lu Haitao and all the staff members sincerely thank new and old customers from at home and abroad over the years for their support. We welcome all customers to visit our company and negotiate
