Low Cost DRO

Specifications

Low cost DRO

1.Packing:

Hard paper cartons,scalses and linears are packed saperately.

2.Shipping:

Air freight and sea freight both ok, according to the quantity and total gross weight.

Low cost DRO

Installment:

If you buy the whole set DRO and want to install in the Lathe machine, milling machine, grinding machine, EDM and so on.

We can install for you.

Low cost DRO

For lathe machine, the scales of lathe in X-axis and Y-axis usually need the thin scale and Z-axis need thick scale.

For milling machine, the X,Y,Z-axis, thick is all ok.

Usually for the two machines, 5μm is all ok.

Low cost DRO

Feature:

1. SDS6 digital readout employs the newest 16bit SCM technology, can substitute all kinds of basic function and special required function of SDS 2 series.

2. An all-purpose DRO the speed of measurement is faster, and the control system is easier and smoother.

3. Each axis can supply 40 points of non-linear compensations.

4. We can get the compensated value through the double-frequency laser measurement machine, floor boring machine, floor boring machine, high accuracy boring machine, high accuracy grinding machine, lathe, EDM machine, milling machine and so on

5. It supplies special function that to control the processing speed of lathe.

6. When you process the wokpiece’s inside/outside in circle by lathe, the DRO can output relative simulative  signal on the basic of the change of the radius of the workpiece to control the principal axis’s transducer.

7. It changes the speed of the principal axis continuously so that we can make the processing speed to the outlook of the workpiece in the same level to achieve the constant speed of processing so that we can promise the coarseness of the complete workpiece are the same.

Different types:

1). According to the scales and display you need, you should need two sets 2-Axis lathe DRO and one set 3-Axis milling machine DRO.

2).According to the thickness, the common we see are KA300 sereis and KA500 series,KA300 is thicker than KA500.

3). According to the resolution, there are 1μm, 5μm and 0.5μm different.

4) According to our experience:

For lathe machine, the scales of lathe in X-axis and Y-axis usually need the thin scale and Z-axis need thick scale.

For milling machine, the X,Y,Z-axis, thick is all ok.

Usually for the two machines, 5μm is all ok.

Specifications:
