Home > Products > Air Condition Unit(AC Unit) > Packaged Rooftop Air Conditioner
Packaged Rooftop Air Conditioner
- Ningbo

You May Like
Product Details
| Type | Water-Cooled | Place of Origin | Zhejiang, China | |
| Brand Name | refworld |
Product Description
Specifications
Suitable to be mounted on rooftops,plant rooms or ground level.About us
About product
The refrigeration system are dfficiency and reliablity.can meet all types of air conditioning
requirements.
Low noise,high static pressure,compact structure.
International famous brand of components and parts.
| Model | Nominal Cooling (kw)  | Rated Airflow (m3/h)  | Maximum Starting  Current (Amps)  | Capacity  Steps  | Sound Pressure  Leveis dB(A)  | Dimension | Net  Weight  | ||
| Length (mm)  | width (mm)  | Height (mm)  | |||||||
| RW-PHT120-195 | 196 | 43200 | 410 | 0.50.100% | 84.4 | 4000 | 2150 | 3600 | 1900 |
| RW-PHT120-205 | 205 | 327 | 84.6 | ||||||
| RW-PHT120-215 | 215 | 381 | 82.9 | ||||||
| RW-PHT120-225 | 227 | 395 | 83 | ||||||
| RW-PHT120-240 | 240 | 409 | 83 | ||||||
| RW-PHT120-255 | 253 | 473 | 84.7 | ||||||
| RW-PHT120-270 | 270 | 476 | 85.1 | ||||||
| RW-PHT120-280 | 282 | 483 | 85.3 | ||||||
| RW-PHT140-220 | 221 | 50400 | 420 | 0.50.100% | 86.2 | 4450 | 2150 | 3600 | 1950 |
| RW-PHT140-225 | 226 | 391 | 86.1 | ||||||
| RW-PHT140-235 | 236 | 405 | 86.1 | ||||||
| RW-PHT140-250 | 249 | 419 | 86.5 | ||||||
| RW-PHT140-265 | 265 | 469 | 86.2 | ||||||
| RW-PHT140-280 | 279 | 476 | 86.9 | ||||||
| RW-PHT140-290 | 289 | 539 | 86.3 | ||||||
| RW-PHT150-240 | 239 | 54000 | 392 | 0.50.100% | 87.1 | 4200 | #### | 3600 | 2560 |
| RW-PHT150-255 | 256 | 426 | 87.1 | ||||||
| RW-PHT150-265 | 266 | 440 | 87 | ||||||
| RW-PHT150-285 | 285 | 490 | 87 | ||||||
| RW-PHT150-300 | 301 | 496 | 87.1 | ||||||
| RW-PHT150-320 | 321 | 503 | 86.5 | ||||||
| RW-PHT150-330 | 328 | 481 | 87.3 | ||||||
| RW-PHT150-340 | 340 | 531 | 87.3 | ||||||
| RW-PHT150-350 | 351 | 538 | 87.4 | ||||||
| RW-PHT150-370 | 370 | 544 | 87.6 | ||||||
| RW-PHT150-380 | 381 | 551 | 87.6 | ||||||
| RW-PHT175-285 | 285 | 63000 | 495 | 0.50.100% | 90.6 | 4200 | 3650 | 3600 | 3000 |
| RW-PHT175-300 | 302 | 501 | 90.6 | ||||||
| RW-PHT175-315 | 314 | 508 | 90.7 | ||||||
| RW-PHT175-325 | 327 | 481 | 90.8 | ||||||
| RW-PHT175-335 | 335 | 531 | 90.8 | ||||||
| RW-PHT175-355 | 354 | 538 | 90.9 | ||||||
| RW-PHT175-380 | 382 | 544 | 91.1 | ||||||
| RW-PHT175-390 | 393 | 551 | 91.2 | ||||||
| RW-PHT200-280 | 283 | 72000 | 407 | 0.50.100% | 93 | 4200 | 4000 | 3600 | 3500 |
| RW-PHT200-295 | 297 | 447 | 93 | ||||||
| RW-PHT200-310 | 312 | 461 | 93.2 | ||||||
| RW-PHT200-325 | 325 | 475 | 93.7 | ||||||
| RW-PHT200-335 | 335 | 489 | 93.7 | ||||||
| RW-PHT200-345 | 346 | 553 | 93.6 | ||||||
| RW-PHT200-360 | 360 | 560 | 93.6 | ||||||
| RW-PHT200-370 | 368 | 566 | 93.7 | ||||||
| RW-PHT200-385 | 383 | 573 | 87.7 | ||||||
NOTE:
1.Nominal cooling capacity is based on 27.0°C DB/19.0°C WB indoor and 35°C DB outdoor.
2.Allowable operating range:Cooling:21.0°C DB/15.0°C WB indoor and 20.0°C DB outdoor to 35.0°C DB/24.0°C WB indoor and 45.0°C DB outdoor.
3.Capacity is gross capacity which does not include deduction for evaporator fan motor heat.
4.Refrigerant charge is approximate value,for more precise value please refer to the unit nameplate or service instructions.
5.All specifications are subjected to change by the manufacturer without prior notice.
6.All units are tested and comply with international standards.
