Home > Products > warehouse rack > heavy duty racking with shelf
heavy duty racking with shelf
- shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | golden peaks | |
| Model Number | GP-WH05 | Type | Multi-Level | |
| Material | Steel | Feature | Other, all kinds RAL color available | |
| Use | Warehouse Rack | Certification | CE | |
| Depth | 0.5mm-1.0mm | Weight Capacity | 1000-1500kg/level | |
| Width | 300mm-1200MM | Height | 1000mm-5000MM |
Product Description
Detailed Specifications:
1. Upright:
70*90*(1.8-2.0)mm
60*80* (1.5-2.0)mm
40*80*(1.5-2.0)mm
30*50*(1.0-1.5)mm
| C-type Upright | ||||
 | Model | Depth(mm) | Width(mm) | |
| U-1 | 70 | 90 | ||
| U-2 | 60 | 80 | ||
U-3 | 40 | 80 | ||
| U-4 | 30 | 50 | ||
2. Beam:
50*100*1.5mm
50*120*1.5mm
50*140*1.5mm
50*80*(1.5-2.0)mm
40*60*(1.0-1.5)mm
30*50*(1.0-1.5)mm
| P-type Beam | Rectangular Beam | |||||||||
| Model | Depth(mm) | Width(mm) | | Model | Depth(mm) | Width(mm) | |||
| B-1P | 50 | 80 | B-1R | 50 | 80 | |||||
| B-2P | 50 | 100 | B-2R | 50 | 100 | |||||
| B-3P | 50 | 110 | B-3R | 50 | 110 | |||||
| B-4P | 50 | 120 | B-4R | 50 | 120 | |||||
| B-5P | 50 | 140 | B-5R | 50 | 140 | |||||
| B-6P | 40 | 60 | B-6R | 40 | 60 | |||||
| B-7P | 30 | 50 | B-7R | 30 | 50 | |||||
3. Shelf: 0.5-1.0mm
Sales Information:
1. Payment terms: 30% deposit paid by T/T, deliver the balance before loading.
2. Delivery time: Within 15 days after receipt of deposit.
3. MOQ: 50 sets.
Remarks:
1. Different requirements(colors, sizes, etc) are available.
2. OEM/ODM is acceptable.
3. Sample order is welcomed.
