Solar collector with heat pipe

Specifications

Solar collector with heat pipe

solar collector system

1.Strong adaptability

2.Wide application occasions

3.High degree of automation solar collector system

General introduction

1.The pipeline is made of red copper and conducted by heat transfer medium liquid.

2.Water cannot flow into vacuum tubes and operated when confined.

3.The crust uses aluminum alloy of high strength with air flow design.

4.It is furnished in good style and can endure high pressure when it is working.

5.Module design, optional combination, which can meet the demand of large water consumption.

Working principle

The  type series solar collector are always connected with existing heating supply device. The selective coating on the inner cover of the evacuated tube converts solar energy into heat energy and transfer ha=eat to metal U tube by an aluminum fin. The liquid usually aglycol water (antifreeze mixture)in the metal U tube is heated, and conducted the heat energy to the water inside the storage tank through plate exchanger or internal spiral coils.

Advantage

1.Strong adaptability

2.Wide application occasions

3.High degree of automation

4.Economical and practical

5.Environmental conservation and energy saving

6.In large-scale projects, we use many-tubes-connected solar collecting system that is composed of solar collectors, storage tank, auxiliary heating system, computerized controller and pipe cycling system

7.According to the required configuration, it can be divided into two types, one is vertical and the other is horizontal; 8.With large heat collecting capacity and hot water output.

Feature

1.The pipeline is made of all the red copper and conducted by heat transfer medium liquid

2.Water cannot flow into vacuum tubes and operated when confined

3.The manifold uses aluminum alloy mould material of high strength with air flow design

4.It is furnished in good style

5.Can withstand high pressure when it works

6.Module design, arbitrary combination, which can meet the demand of large water consumption

7.Can operate with water pressure up to 0.6 Mpa

8.Can be combined with existing energy source

9.Storage do not need be installed above the collect

Specification

1.Manifold(interior):red copper

2.Manifold(exterior):aluminum alloy;

3.Glass tube dimensions:58mm×1.8mm/47×1.5

4.Daily efficiency:≥55%(≥42% in winter)

5.Hail resistance:25mm

6.Max pressure:12 Bar

7.Coating of vacuum tube: ALN/AIN-SS/CU

8.Heat pipe: anti-freezing greater than -35 °C
