35800 union special industrial sewing machine

Specifications:

Name                             QM-35800

Sewing form                  three needles six threads sewing machine

Function                        medium~ high thickness: jeans, labor jacket, uniform

Max sewing speed        4500rmp

Stitch length  6.4mm(1/4”)

Sewing length                          2.1mm~3.6mm(standard 3.2mm)

Needle/standard sewing      UY130GS(standard)/Nm140(#22)

Needle bar area            33mm

Stitch conductor           6conductors

Weight(head)                23.5kg

Presser foot lift             Max 9mm(6.5mm for factory)

Tug on the feed width  11.9mm

Feed adjustment method     Main feed: slide length adjustments

Lubricating method      Automatic rotary pump oil

Machine oil                   Juki machine oil NO.18

Installation method      Aid drive assembly  MT103 mounted on the machine

Why us:
1. We focus on researching and producing sewing machine since 1993.
2. We passed ISO9001:2008 quality management system certification.
3. We have 5 master technicians available during business hours if you have any Questions.
4. We offer special design services to meet your personal demands.
Warranty: one year     long lifespan
