Heat Resistant Nylon Conveyor Belt/High Temperature Resistant/Tensile Strength 900N/mm

FOB Price

US$ 2.6 - 2.6 / Meter

20 Meters(Min. Order)

Port TIANJIN QINGDAO OR AS YOUR DEMANDS
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China		Brand Name	ELEPHANT
Model Number	EL-NN19

Product Description

Heat Resistant Nylon Conveyor Belt/High Temperature Resistant/Tensile Strength 900N/mm

Product Description

Description :

To prevent possible damage when operating in hot working conditions , we developed different types of hot-resistant conveyor belts . When choosing the most appropriate type of heat-resistant conveyor belt all operating conditions should be considered : temperature of the transported material ,ambient temperature in the production process , size of pieces of the material , contact duration between the conveyor belt and the material .

Types & Physical Performance :

Item	150℃	180℃	200℃
Tensile Strength	≥14 N/mm²	≥14 N/mm²	≥13 N/mm²
Abrasion	≤250 mm³	≤250 mm³	≤200 mm³
Elongation at break	≥400%	≥400%	≥350%
Const. Operating Temperature	≤150 ℃	≤180 ℃	≤200 ℃

Type And Applications :

Materials Carried	Lump Size	Temperature of Material Carried	Belt Surface Temperature
Sintered Ore	25-200 mm (1-8 inch)	200-400ºC (390-750ºF)	130-150ºC (270-300ºF)
Return of Sintered Ore	Below 10 mm (0.4 inch)	260ºC (480ºF)	150-190ºC (300-370ºF)
Coke	100-200 mm (4-8 inch)	70-100ºC (160-210ºF)	50-60ºC (120-140ºF)
Raw Material	Below 30 mm (1.2 inch)	180-220ºC (360-410ºF)	100-120ºC (210-250ºF)
Clinker	10-30 mm (0.4 – 1.2 inch)	100-220ºC (210-440ºF)	100-110ºC (210-230ºF)
Cement	Powder	100-125ºC (210-250ºF)	80-90ºC (170-190ºF)
Metal Powder	–	170ºC (340ºF)	120-130ºC (250-270ºF)
Molding Sand	–	200-250ºC (390-480ºF)	80-90ºC (170-190ºF)
