80KL Bulk Fuel Tanks & Self Bunded Tanks for On-site Bulk Fuel or Lubricant
- SHANGHAI
- T/T
You May Like
-
12KL Unleaded Fuel Bunded Tank Containers, 110% Secondary Containment
-
20ft ITP SERIES CONTAINERISED TANKS, Fuel Storage Tanks, Double Walled
-
10ft ITP Unattended Service Station, Retail Above Ground Service Stations
-
40ft ITP SERIES CONTAINERISED TANKS, Fuel Storage Tanks, Double Walled
-
Mining Pumping Package, Refueling Equipment
-
ITP TANKS Fuel Dispensing System, Mobile Fuel Station
Product Details
| Condition | New | Capacity | 80KL | |
| Place of Origin | Jiangsu, China | Brand Name | INTECH | |
| Model Number | ITS-80 |
Product Description
ITS-80 Double-walled Bulk Diesel Fuel Storage Containers
A major feature of the self-contained tank is the “tank within a tank” design; creating an interstitial space that alleviates the need for external containment or retaining wall. INTECH self-contained steel tanks meet SPCC containment requirements. There is no contaminated water to drain or leaf debris to remove, and fuel remains secure within the tank at all times.
Standard tanks are supplied empty with a range of options available including pumping packages, fuel management systems, filtration and other “bolt-on” components depending on your application.
- Self bunded or double wall design
- Overfill protection supplied with mechanical shutoff and audible / visual alarm
- Free to air vent with weather cap
- Calibrated fluid level dipstick
- Antisyphon valve installed
- Ladder can be fitted to either side
- Water collection well complete with evacuation pipe
- Bunded (spill contained) pump bay housing with removable ventilation panels
- Front mounted security doors
- Statutory signage
SPECIFICATIONS | |
STANDARD FITTINGS: 80NB Camlock male tanker hose filler with dust cap connect, Tanker full point supplied with 80NB full bore fire safe flanged ball valve and wafer style non return valve, container corner castings, statutory access manway, permanent ladder and platform, water evacuation pipe, interstitial space fluid dipstick, containment compartment with pressure vent, marine grade polyurethane paint (white in color) | |
Capacity (full) Litres: 81,500 | Design Compliances: UL142, ULCS601, AS1940, AS1692, AS1657 |
Safe Fill Level Litres: 73,500 | |
Weight Bare Tank (kg): 17,000 |
|
Dimension Width (mm): 2438 mm |
|
Dimension Length (mm): 14630 mm |
|
Dimension Height (mm): 2896 mm | |
