API Standard Sucker Rods-China Sucker Rod-Oilfield Hollow Sucker Rod
- 0 per Month
- Tianjin&Qingdao
You May Like
-
C, K, D, KD, HL, HY and KH.C, K, D Sucker Rod Standard
-
API Spec 11B sucker rod 5/8'',3/4'',7/8''
-
Grade H Sucker Rod API Spec 11B
-
High Quality Titanium Polishing Rod for Oil Extraction
-
Titanium Polishing Rod with High Quality For Oilfield Oil Extraction
-
Oilfield API 11B Standard Polished Rod for Oil Drilling with Sucker Rod Pump
Product Details
| Place of Origin | Hunan, China | Brand Name | ZS | |
| Model Number | API | Type | Other, Sucker rod | |
| Machine Type | Drilling Equipment | Certification | API | |
| Material | Other, Carbon Steel, Carbon Steel | Processing Type | Forging | |
| Use | Well Drilling |
Product Description
API Standard Sucker Rods-China Sucker Rod-Oilfield Sucker Rod
1.Features of API Spec 11B sucker rod:
The sucker rod is a steel rod that used to make up the mechanical assembly between the surface and downhole components of a rod pumping system.It is including main grade C and D.Grade H sucker rod made of high quality structural steel is the super strength and developed to suit for deep well, larger pumps and other heavy load.All sucker rods that our company provided standard with API specification 11B,quality class.
2.Following is the main technical parameters of API Spec 11B sucker rod:
Sucker Rod OD in(mm) | 5/8(15.88) | 3/4(19.05) | 7/8(22.23) | 1(25.40) | 1 1/8(28.58) |
Thread OD in(mm) | 15/16(23.81) | 1 1/16(26.99) | 1 3/16(30.16) | 1 3/8(34.93) | 1 9/16(39.69) |
Coupling OD in(mm) | 1 1/2(38.10) | 1 5/8(41.28) | 1 13/16(46.04) | 2 3/16(55.56) | 2 3/8(60.33) |
Standard Length ft(mm) | 30(9140) 26(8000) 25(7620) | ||||
3.Mechanical Parameter of API Spec 11B sucker rod:
Grade | Min Y.S | Min T.S | Max T.S |
C | 60000(414) | 90000(620) | 115000(793) |
D | 85000(586) | 115000(793) | 140000(965) |
H | 115000(793) | 140100(966) | 164800(1136) |
All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time. If you are caught in some problems when using our products, welcome to contact us at any time.
