High Quality Chinese Hydraulic Excavator CT45-7A
Negotiable
/ Set
1 Set(Min.Order)
- 1000 Set / Sets per Month
- Qingdao Port China
- T/T L/C Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | WISH | |
| Model Number | CT45-7A | Condition | New | |
| Moving Type | Crawler Excavator |
Product Description
Specifications
Excellent quality with competitive price; Original ISUZU engine; World famous brand hydraulic system and other key parts.Production Feature:
American made engine A23W00
Power 32KW/2200RPM, a guarantee of super power
In conformity with the EU III emission control regulations
Imported hydraulic system with dual pump and dual circuit
Guarantee for 3 yrs under normal use and maintenance
Imported hydraulic components, Japan made KYB main pump, multi-circuit valve, swing motor, walking motor, South Korea made gasoline tank
America made engine CUMMINS A2300(4-88X94)
On-line digital monitoring and control system
GPS satellite position(optional)and remote diagnose system(optional)
Light and handy pilot operating system
Cold&warm air conditioner supply under different kinds of weather conditions
Rubber pedrail or steel pedrail
Specification:
| name | parameters |
| Operating weight | 3.900 KG |
| Travel speed | 4.4/2.7km/h |
| Bucket Capacity | 0.14-0.18m3(SAE) |
| Tracking force | 34.1kn |
| Engine power | 32KW 2.200RPM |
| gradeability | 30°(58%) |
| Swing speed | 11RPM |
| Bucket digging force | 23.7 kn |
| Ground Pressure | 33KPa |
| Arm digging force | 18.5 kn |
| Dimensions | |
| name | parameters |
| Boom Length | 2.650mm |
| Arm Length | 1.600mm |
| Upperstructure width | 1.500mm |
| Undercarriage width | 1.630mm |
| Overall Height with cabinet | 2.455mm |
| Rear swing radius | 1.600mm |
| Clearance under counter weight | 585mm |
| Tumbler Distance | 1.710mm |
| Ground clearance | 350mm |
| Overall length for transportation | 5.560mm |
| working range | |
| name | parameters |
| MAX digging radius | 5.720mm |
| MAX digging radius at ground lever | 5.610mm |
| MAX digging depth | 3.700mm |
| MAX vertical wall digging depth | 3.200mm |
| MAX digging height | 5.050mm |
| MAX dumping height | 3.500mm |
| MAX dozer cutting depth | 380mm |
| MAX dozer lifting height | 255mm |
