2014 New CT60-6A Earth Moving Machinery Crawler Excavators

FOB Price

US$ 43,000 - 45,000 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	wish
Model Number	CT60-6A

Originally imported Japan Yanmar 3TNV82A diesel engine;
Originally imported US Parker double-connecting gear pump;

Specification of Carter CT60-6A excavator

Excavator model			CT60-6A with cab
Cargo body size (LxWxH)(mm), 20GP:569021302180			load 2 units in one 40HQ container
Operate weight kg			5900kg
Bucket capacity M3			0.2m³
Engine model			Cummins B3.3
Engine power(kw)			45Kw
Swing speed(rpm)			10
Ground pressure(KPa)			34
Travel speed(km/h)			4.0/2.5
Tracking force(kn)			49.3Kn
Gradeability(°)			30°(58%)
Main dimensions	Upperstrcuture witdth(mm)		1785
	Undercarriage width(mm)		1880
	Cabinet height(mm)		2650
	Rear swing radius(mm)		1700
	Ground clearance(mm)		400
Working range		Max.digging radiusmm)	6245
		Max.digging depth mm)	3875
		Max.digging height(mm)	5785
		Max.dumping height(mm)	4095
		Max.dozer cutting depth(mm)	505
		Max.dozer lifting height(mm)	300
Standard Equipment		Germany Roxroth main pump
		U.S.A Parker reducer and travel motor
		US Parker swing motor
		US Parker multi-circuit valve
		Japanese Bridgestone rubber track
		Cold&warm air conditioner supply under different kind of weather conditions
