HJK-50 Clay Brick Machine/Double-Stage Vacuum Extruder

Type	Hollow Block Making Machine		Brick Raw Material	Clay
Processing	Brick Molding Machine		Method	Vacuum Extruder
Automatic	Yes		Capacity	12000-16000pcs/h
Place of Origin	Henan, China		Brand Name	HONGJI
Model Number	HJK-50		Power	132kw

Specifications

1.high technology
2.easy operation
3.large output
4.low-power motors
5.easy operating

 HJK-50 Clay Brick Machine/Double-Stage Vacuum Extruder



Brick making machine:



     The HJK series are advanced twin-stage vacuum extruder which draw lessons from the developed domestic, abroad experiences and design to make. They are mainly made of high quality steel with features of reasonable structure, sturdy and durability. And they have strong applicability, high efficiency, easy maintenance but lower energy consumption.

   The machine’s axles, gear and other important spare parts extend the service life which are made by carbon steel and alloy steel through modulation or quench’s heat treatment procession. The dialing mud plate’s transfer and material level control are fixed with protecting device which improves the plant efficiency of breakdown maintenance. And it also makes sure that it can’t easily damage the main spare parts during usage. The reamer adopt the floating shaft structure which can eliminate and reduce the machine’s shaking and rocking timesbecause of curve in principal axle after long time usage.

       The blades of the reamer adopt the wear-resistant metallic material coating technology which makes its life four times to seven times longer than the common reamer. The lead has the function of slight pressure delivery and high pressure extrusion which make the machine save energy from fifteen percent to thirty percent. They are applicable for the production of high-rate hollow bricks with the materials of coal gangue, shale, high-volume fly-ash, urban construction waste, gangue waste, inferior soil.



Technical  parameter:



Model No.	HJK-50
Productivity	12000-16000pcs/h
Diameter of the cutter knife	500mm
Maximal extrusive pressure	3.0Mpa
Vacuum degree	92%
Power	132KW
Dimension	6100*2100*2300(mm)











About our machine:

It’s the latest all steel double level vacuum extruder. In design and development of it, we absorbed the advanced the advanced technology of congener productions from home and abroad, and use the advantages of various models for reference. Therefore, it has rational configuration, excellent applicability and high efficiency. And it’s sturdy and durable.It’s convenient to fix and maintain. It can be remote controlled. No doubt, this machine is ideal brick manufacture equipment for using materials of clunch, shale, coal gangue.
