Small Hole Drilling EDM
US$ 1.333 - 383,838
/ Set
1 Set(Min. Order)
- Any port of China
- T/T Credit Card
You May Like
Product Details
| Condition | New | CNC or Not | CNC | |
| Drilling Speed | 60 mm2/min | Place of Origin | Jiangsu, China | |
| Brand Name | BAOMA | Model Number | BMD703-400 | |
| Voltage | 380V | Power(W) | 3.5 KVA | |
| Dimension(L*W*H) | 1236 x 1025 x 1934 | Weight | 700 | |
| Certification | CE, ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Hole Drilling EDM ,can drilling Tungsten Carbide,Brass/Copper Tube electrode, Dia. 0.2-3.0mm
Depth: 0-300 mm
Speed: 60 mm2
| Specification | BMD703-400 | Universal Parameter | ||
|---|---|---|---|---|
| Work table Size | 310x 486 mm | Drilling Depth | 0 - 300 mm | |
| Work Table Travel | 300 x 400 mm | Z axis Travel | 300+(320) mm | |
| Load of Table | 300 Kg | Max. Drilling Speed | 60 mm2/min | |
| Electrode Diameter | 0.2-3.0 mm | Max. Working Current | 30 A | |
| Water Tank Capacity | 30 L | Max. Power comsumption | 3.5 KVA | |
| Machine Weight | 700 Kg | Voltage | 220-415V / 50HZ | |
| Machine Dimensions | 1236 x 1025 x 1934 mm | Working Solution | Water/Saponification | |
| Packing Dimensions | 1430 x 1340 x 2000 mm | Function of setting depth | Yes | |
| Control Type | ZNC: Z axis NC Control | Z axis Travel Control | Electric Motor | |
