Vacuumforming Plastic Parts for Brand Car

Specifications

Vacuumforming plastic parts for brand car

.Competitive price with high quality

. Quick delivery , sample lead time 7-10 days
.Vacuum forming process low mold cost

. OEM design

Description

 Shenzhen Amei Brothers Plastic Co., Ltd are able to make all kinds of vacuum forming products

. Competitive price with high quality  ISO certified manufacturer

. Material available : PPPVCPEPCPSPETGPETABSAcrylic/PMMA the thickness can reach 10mm

. Low mold cost, sample lead-time 7-10 days

.Vacuum forming process and we are able to do silkscreen print , spray paint, plating, engraving,   glue, sticker,assemble

.OEM design and the Max dimension  can be  3000*2000*800mm

.Third party inspection acceptable

.Delivery time 20days after confirmation of the sample

.Payment: 50% payment as deposit in advance by T/T , and  balance before shipment

.MOQ : 500pcs per order per design

.Package:We use EPE, carton, or other required packing materials to keep the package safe and effective. We are capable to meet your special packaging requirements

Please contact us if we can be of any help

  vacuum forming process for your reference

1. Extruding plastic sheet:

ABS, HIPS, PP, PE, PC, PETG, PMMA resin granules are extruded or co-extruded into thermoplastic sheet--textured, smooth, gloss or matt, fire-retarded or UV resisted

2. Vacuum forming to shape:

After being heated, the plastic sheet is stretched onto or into a mould, and held against the mold by applying vacuum between the mould surface and the sheet to form desired shapes.

3. Cooling to maintain shape:

Once formed the plastic need to cool before being released from the mould. To speed up the cooling cycle, fans are fitted and activated once the plastic part is formed.

4. Making large product:

Our machine could be restructured to make larger plastic ABS thick vacuum forming plastic shell, with maximun dimensions of 3000*2000*800* (L*W*H*T)

5. Trimming edges:

Extra material is firstly trimmed before more accurate processing. Sawing is often used in this stages. Polishing is made additioanlly to smoothen the edges.

6.Drilling holes:

Drilling oftens follow the trimming. Other post forming processes include decoration, printing, strengthening, reinforcing and assembly.

7. CNC Processing:

 CNC  machine is computer programmed to select the correct cutting tools and angle to suit each cutting area.

8.Examination and checking:

Before packaging, all our thick vacuum forming samples and products will be carefully checked in terms of dimensions, surface finish, stenghth, colour requirements and so on.

9. Cleansing and Packaging
