Home > Products > Paper Cup & Plate Making Machinery > JBZ-A Automatic Paper Cup Forming Machinery
JBZ-A Automatic Paper Cup Forming Machinery
- T/T
You May Like
Product Details
| Product Type | Paper Cup Machine | Place of Origin | Zhejiang, China | |
| Model Number | JBZ-A |
Product Description
Specifications
paper cup forming machineryJBZ-A Paper Cup Forming Machine is an automatic machine with multi-working station.
paper cup forming machinery
JBZ-A Paper Cup Forming Machine is an automatic machine with multi-working station. It produces one-side film-coated paper cup through the procedure of automatic paper feeding, sealing, oil silicon lubrication, bottom punching, heating, knurling, curling and cup discharge. This kind of cup can be for tea, coffee, milk , ice-cream etc.
Technical specification | |||||
Model | JBZ-A04 | JBZ-A12 | JBZ-A16 | JBZ-A22 | JBZ-A36 |
Cup size | 2,3,4,5,6 oz (for ice-cream) | 6,8,9,12 oz | 12-16oz | 16-22oz | 22-36oz |
Raw material | one side PE coated paper | ||||
Capacity | 40-50pcs/min | 40-45pcs/min | 30-40pcs/min | 30-35pcs/min | 30pcs/min |
Power source | 380V 50Hz(it can be changed if customer require) | ||||
Total power | 4.5KW | 5kw | 6KW | 11kw | 11kw |
Weight | 1600Kg | ||||
Package size | 2800*1320*1800mm | 2800*1320*1800mm | 3000*1320*1950mm | 3300*1450*2050mm | 3550*1450*2150mm |
(L*W*H) | 730*600*1100mm | 730*600*1100mm | 730*600*1100mm | 800*750*1300mm | 850 |
