500N Digital Display Electronic Universal Testing Machine ( Single Column )

It is applicable for wide range of material for tension, compression, bending, shearing and low cycle test.

Suitable for metal, rubber, plastic, spring, textile, and components testing. It is widely used in the corresponding industries, research and development, test institutes and training centers etc.
Standard:
ASTM, ISO, DIN, GB and other international standards.
Main Technical Parameters:
1.Model:WDS-05D
2.Max. load:500N
3.Structure:Single column double spaces
4.Control method:Single chip control
5.Load accuracy:1 class
6.Load range:2%~100%F·S/0.4%-100% FS
7.Displacement Resolution:0.01mm
8.Test speed:0.05-500mm/min(can be customized)
9.Tensile space:600mm (can be customized)
10.Compression space:600mm(can be customized)
11.Power supply:AC220V±10%,50Hz(can be customized)
12.Grips:Wedge type, plate type and other grips as consumer’s demand
13.Dimension:520*390*1690mm
14.Weight:124kg

Feature:
1. Automatic stop: After the sample broken, automatic stop.
2. Display: Real-time display testing force, displacement, testing speed, peak value, testing status on one LCD.
3. Automatic return: automatic return to initial position when testing finished.
4. Limiting protection: Program control and Mechanical limiting protection.
5. High accuracy photoelectric encoder to measure the displacement
6. High accuracy load cell to measure the test load
7. Ball screw no backlash to guarantee the low noise and high driving efficiency
8. High accuracy servo motor to control test speed
9. Adopt reliable, durable and high accuracy digital electronic device
10. Can built-in multiple load sensor control channel
11. Thousands of test fixture can be used according to different test request
12. Micro printer optional, can realize testing data print

1.Outside packeg: wooden case
2.Inside package: strength film and foams
