JR-X6B-TF Usb Audio Module / PCBA

BM-X6-TF audio mp3 decoder board

Quick Details :

1, Functions instruction

Features:

1.Support  Key function:Last song, next song, Volume control,EQ, Play/Pause,repeat .

2.Support to switch external signals directly

3.Support IR remote control in 8 meter

4.Support  SD card or MMC card for playback

5.Support MP3/WMA format

6.remote control / remote control circuit board

7. Support usb sd card mp3 player circuit board

usb sd mp3 digital player

2, Operation in Remote control:

1, PLAY/PAUSE :In MP3 MODE:Press PLAY/PAUSE button to select the PAUSE OR PLAY.In

RADIO MODE: PLAY/PAUSE button to select the preset station #1. #1 to 6 is the same as the

function in the RADIO MODE.

2,MODE:Press MODE button to select the Tuner,AUX,MP3.

Press MODE button in Remote control (or Press Play / Pause button for 1 second in Key board)to select the Tuner,AUX ()Line in mode,the music is playing from Line in.

3,MUTE:Press MUTE button to select MUTE, Press it again will resume the soundLine in  PLAYINGPlug the Line in.

EXTERNAL KEY BOARD ,CONNECTER TO CON2 FROM MAIN BOARD:With the USB cable to the USB port on the main board to connect to the computer's USB port, you can from your computer to manage TF card files or download any music files to theTFcard

Company Brief Introduction

Founded: 2011

Total Staff: 21-50,including around 5 R&D Staff

Product Line: mini Card& USB reader speaker, portable FM radio speaker, MP3 decoder board, Car no disk drive , Magic ball stage light mp3 decoder board, MP3 bluetooth , ect.

We can add USB/SD function or USB/TF function and FM radio on  MP3 decoder board , mini speaker, Car no disk drive

Remarks: 1) More new designs are on the way

                 2) We do best service to every customer, the more you order, the better price you will get.

                3) If you have any problems, please feel free to contact with us.
