CCC 19510 approved 42V 0.8A LED Power Supply

Application

Widely used in medical,digital,communication,security,lighting, DVD players, LCD and TFT TVs, MP4 players, digital cameras, surveillance video camera,other A/V products,cell phone charger,network information,security equipment,small home appliances,etc.

Electric specification:

1. input voltage :AC100V-240V
2. output voltage:DC42V
3. output current:0.8A

Features:

1. low consumption:0.3(up to CE standard)
2. small volume ,light weight ,easy to carry
3. Defect rate:0.3%
4. Warranty:2year

Specifications

Our products have the advantages:
1.easy to carry and compact size

Products information

1. 1. Name: FY4200800
2. 2. Frequency:50/60HZ(47/63HZ)
3. 3. Output power :33.6W
4. 4. Output voltage: 42V
5. 5. Output current : 0.8A
6. 6. Line regulation : ±1%
7. 7. Load rang : ±5%

Products Protection

1.Insulation resistance: DC 500V/100MΩ

2.Overvoltage protection:120%MIN

3.Overcurrent protection:120%MIN

4.Dielectric Strength test :AC 3000V/5MA

5.Operating temperature:0-40°C

6.Storage temperature:-20-85°C

7.Operating Humidity:5-95%ROHS

8.No Load Power Consumption:<0.3W

9.Efficiency:70% Min

10.Storage humidity: 5-90%RH

11.Working Temperature:0-40oC Max

12.Storage temperature:-20-+80C

13.input current(max): 0.53A

14.Short Circuit Protection

15.Over Current Protection

16.Over Voltage Protection

Safty certificates

FCC,GS,CE(LVD/EMC),RoHs,PSE,SAA,C-tick,UL,BS,CB etc.

Warranty & Test

1.two years warranty

2.Average fault-free time 50000 hours at 25°C.

3.Burn-in test: the products have been tested by 4 hours under normal input and 80-100% rated load at 40°C±5°C

CERTIFICATION

50pcs/ctn
size of carton:41.5*37*17CM3
