Rubber and Plastic Kneader
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | Double Elephants | Model Number | from X(S)N-3/40 to X(S)N-110/30 | |
| Voltage | 220V/380V | Power(W) | from 7.5KW to 185KW, please check below details | |
| Dimension(L*W*H) | from 1670x950x1880mm to 4225x1980x3180mm, please check below details | Weight | from 1.2T to 11T, please check below details | |
| Certification | ISO | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
quick kneader ,kneader mixer, kneader machine in ISO
Features:
1 The machine adopts pass base plate, easy to installation and calibration.
2 USe hard teeth face reducer for tranmission, which works smooth, has low noise and long life.
3 The mixin mill chamber is made of alloy steel, surface plating hard chromium, wearable and beautiful.
4 The roller is made of alloy steel, the ribs are welded of hard alloy and surface plated hard chromium. It's smooth and wear-resistant, the roller is bored type, can cooling or heating(steaming, oil heating etc.).
5 Sealing structure adopts international advancedtechnology, good sealing effect.
STYLE | MIXING VOLUME CHAMBER (L) | ROTOR SPEED (R/MIN) | MAIN MOTOR POWER (KW) | TURNING OVER ANGLE | COMPRESSED AIR WORKING PRESSURE(KG/M2) | OVERAL DIMENSION(LXWXH) (MM) | WEIGHT (T) |
X(S)N-3/40 | 3 | 40/31 | 7.5 | 140º | 8 | 1670x950x1880 | 1.2 |
X(S)N-10/40 | 10 | 40/31 | 15 | 140º | 8 | 2300x1350x2120 | 2.3 |
X(S)N-20/40 | 20 | 40/31 | 37 | 140º | 8 | 2360x1750x2430 | 4.5 |
X(S)N-35/30 | 35 | 30/24.5 | 55 | 140º | 8 | 3240x2079x2650 | 6.5 |
X(S)N-55/30 | 55 | 30/24.5 | 75 | 140º | 8 | 3400x2300x3100 | 7.5 |
X(S)N-75/30 | 75 | 30/24.5 | 110 | 140º | 8 | 3860x2300x3375 | 10 |
X(S)N-110/30 | 110 | 30/25 | 185 | 140º | 8 | 4225x1980x3180 | 11 |
COMPANY INFORMATION
Shanghai double elephants rubber and plastic machinery co., LTD., founded in 1994, specializing in the production and distribution group of companies affiliated factory production of rubber and plastic machinery, PVC film, artificial leather In addition, we also can according to user requirements design and manufacture non-standard equipment.Our products have been exporting to more than 100 countries and regions, such as USA ,Italy, French, Germany, Japan, Russia, Korea, India ,South America ,Africa with highly reputations around the world.
GUARANTEE & AFTER-SALE SERVICE
1,One year guarantee for whole machine except tubes
2,24 hours technical support by mail
3,service station in your country, quick response
quick kneader ,kneader mixer, kneader machine in ISO
