Production Line of Nails Making Machine

FOB Price

US$ 1,000 - 8,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	wxwds
Model Number	Z94 Series		After-sales Service Provided	Engineers available to service machinery overseas

Automatic Wire Nail Making Machine
1.Adopts plunger type structure
2.High working speed
3.Low noise
4.Low impa

Features:

This machine adopts plunger type structure to ensure its high working speed, low noise and low impact characteristics.

Especially it can make high quality You Mao nails which used for high speed welding machine and nail gun, and it can make nails for other use.

Technical parameter:

Model	Z94-4C Automatic nail making machine
Max. dia. of nail	4.5mm
Min. dia. of nail	2.8 mm
Max. Length of nail	100mm
Min. length of nail	50 mm
Motor power	4kw
Nail making speed	260pcs/min
LWH	2.21.61.65m
Weight	2tons

Other items of C series for your choice:

Model	Z94-1C Automatic nail making machine	Z94-2C Automatic nail making machine	Z94-3C Automatic nail making machine	Z94-4C Automatic nail making machine	Z94-5.5C Automatic nail making machine
Max. dia. of nail	1.6mm	2.8mm	3.5mm	4.5mm	5.5mm
Min. dia. of nail	0.9mm	1.2mm	1.8mm	2.8mm	3.8mm
Max. Length of nail	25mm	50mm	75mm	100mm	150mm
Min. length of nail	9mm	16mm	30mm	50mm	80mm
Motor power	1.5kw	2.2kw	3kw	4kw	5.5kw
Nail making speed	450pcs/min	350pcs/min	320pcs/min	260pcs/min	200pcs/min
LWH	1.51.31.2m	1.71.31.4m	2.01.41.4m	2.21.61.65m	2.51.61.5m
Weight	1.2tons	1.45tons	1.8tons	2tons	2.3tons
