Home > Products > GENERATOR SETS > Air Cooling Deutz Diesel Generator Set
Air Cooling Deutz Diesel Generator Set
- Fuzhou
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | Jinlong/OEM | |
| Model Number | GF-DD105 | Output Type | AC Three Phase | |
| Speed | 1500/1800rpm | Frequency | 50/60hz | |
| Rated Power | 100KVA | Rated Voltage | 220/380V,230/400V,110/208V,127/220 | |
| Rated Current | depend on power |
Product Description
Air cooling Deutz diesel generator set
1.Design Patent Product
2.100% copper wire
3.Top zinc-plate fuel tank
4. No losing power
3-PH, 50Hz@1500RPM, 220/380V (Also Can Be Made According To Customers’ Special Requirements)
Composed of DEUTZ (water cooled) diesel engine and Stamford Alternator
24V DC start motor and storage battery
Brushless, Self-excited, IP23, insulation class F alternator
40°C radiator as standard, 50°C is optional
Key start panel control system as standard, digital auto-start panel is optional
Optional open type or silent type
All generator sets are gone through rigorous testing before being released to the market place.
Prime Power | 80KW/100KVA | Standby Power | 88KW/110KVA |
Rated Speed | 1500RPM | Output Frequency | 50HZ |
Phase | 3 | Rated Voltage | 400V |
Engine Model | TD226B-6D | Alternator Model | UCI274C |
Noise(7m)dB(A) | 70 | Fuel Consumption (g/kw.h) | 208 |
Voltage Regulation Rate | ≤±1% | Random Voltage Rate | ≤±1% |
Frequency Regulation Rate | ≤±5% | Random Frequency Variation | ≤±0.5% |
Dimension (Silent type) | 2600X1060X1700 (mm) | Weight (silent type) | 1540kg |
Engine Specifications
DEUTZ Diesel Engine
Engine Model | TD226B-6D |
Number of Cylinder | 6 |
Cylinder arrangement | Vertical in-line |
Cycle | Four Stroke |
Aspiration | Turbocharged |
Bore×Stroke (mm×mm) | 105×120 |
Displacement (L) | 6.23 |
Compression Ratio | 18:1 |
Prime Power/Speed(KW/rpm) | 60/1500 |
Standby Power/Speed(KW/rpm) | 66/1500 |
Speed Governor | Mechanical |
Cooling System | Water-cooled |
Speed Stability(%) | ≤5% |
Fuel Consumption at 100% Load(g/kwh) | 208(at 1500RPM) |
Starter Motor | 24V |
Alternator | 24V |
Alternator Specifications
Alternator Model | UCI 274C |
Alternator Brand | Stamford |
Exciter Type | Brushless, Self-excited |
Rated Output | 80KW |
Rated Speed | 1500RPM |
Rated Frequency | 50HZ |
Phase | Three |
Rated Voltage | 400V (Available with customer requirements) |
Power Factor | 0.8 |
Voltage Adjust Range | ≥5% |
Voltage Regulation NL-FL | ≤±1% |
Insulation Grade | H |
Protection Grade | IP23 |
Features:
Low consumption and low noise
Powerful load capacity.
AMF/ATS
1 year warranty
Base fuel tank
Open typr or Silent type
Our work shop

Payment;
30% deposit(T/T),balance (70%) to be paid before shipment.(for bulk cargo)
30% deposit(T/T),balance (70%) to be paid after receipt of the B/L copy.(For container order)
L/C at sight. (For container order)
Warranty
A guarantee of 1200 hours or 12 months from date of commissioning or 18 months from shipping, whichever occurs first, is provided. Warranty will be invalid if customer disobey the requirements of the operation and maintance in Generator Set Technical Manual.This is supported by the added operation and maintenance backing of the principal component manufacture, global service networks.
Fujian Jinlong Electrical Machinery Group Co., Ltd (JINLONG GROUP for short) was established in 1994 JINLONG Group regards electromechanical industry as the core, and involves International Trade, Finance, Investment E.T.C. After years of unremitting efforts, our company has developed into a certain scale of comprehensive, international group co., LTD.
Have passed ISO 9001:2008, CE, GS Certificate e.t.c.. Brand “Jinlong” is “FUJIAN PROVINCE FAMOUS TRADEMARK” & “FUJIAN PROVINCE FAMOUS BRAND PRODUCTS” that is recognised by international customers. Products are sold in European, South America,South-East Asia, Middle East, Africa e.c.t over 80 countries and areas. Favored by the majority of customers.
