Cable Connector
USD $0.05 - $0.5
/ Piece
500 Pieces(Min.Order)
- Shanghai
- T/T
You May Like
Product Details
| Material | Zinc | Technics | Casting | |
| Type | Bushing | Place of Origin | Shanghai, China | |
| Model Number | DDP | Brand Name | GAOHE | |
| Connection | Female | Shape | Equal | |
| Head Code | Hexagon |
Product Description
Specifications
DDP Waterproof Cable ConnectorWaterproof/Liquidtight Straight Cable Gland
DDP Waterproof Cable Connector
Waterproof/Liquidtight Straight Cable Gland Specification,
1, Zinc alloy die casting with zince plated.
Chromium or nickel plated are also available.
2, Thread specification: Metric, PG, G, NPT etc.
3, Waterproof, liquid tight type
4, Green material, special desighnation, good strengths and none damage to electrical machine.
| Nominal Diameter (mm) | Cable Specification | Screw Thread Connected | ||||
| British Standard Pipe Thread(BSP) | Thin Steel | Metric System | Germany System | |||
| 6 | 3-6 | G1/4″ | C13 | M14×1.5 | M12×1.5 | PG7 |
| 8 | 6-8 | G1/4″ | C15 | M16×1.5 | M14×1.5 | PG9 |
| 10 | 8-10 | G3/8″ | C15/C19 | M18×1.5 | M16×1.5 | PG11 |
| 12 | 10-12 | G1/2″ | C19 | M20×1.5 | M18×1.5 | PG13.5 |
| 14 | 12-14 | G1/2″ | C19 | M22×1.5 | M20×1.5 | PG16 |
| 18 | 14-18 | G3/4″ | C25 | M27×2 | M24×1.5 | PG21 |
| 25 | 18-25 | G1″ | C31 | M36×2 | M33×2 | PG29 |
| 32 | 25-32 | G1/4″G1/2″ | C39 | M48×2 | M45×2 | PG36 |
| 38 | 32-38 | G2″ | C51 | M54×2 | M60×2 | PG42 |
| 44 | 38-44 | G2/1/2″ | C63/C75 | M64×2 | PG48 | |
