Hardgrove Grindability Index Tester
- Qingdao Shanghai Tianjin ..
- T/T Credit Card
You May Like
-
Manual Hollow Brick Making Machine,Brick Forming Machine Manual
-
Manual Brick Making Machine,Brick Forming Machine Manual
-
Clay Brick Making Machine, Manual Brick Making Machine
-
Clay Brick Making Machine, Manual Brick Making Machine
-
JZC Series Concrete Mixer
-
Clay Brick Making Machine, Clay Brick Maker
Product Details
| Place of Origin | Henan, China | Brand Name | Amisy | |
| Model Number | AMS-HGI |
Product Description
Specifications
Hot Hardgrove Grindability Index Tester1.Testing the coal grindability by Hardgrove method
2.Auto-lifting/loading/counting
Hotsale Hardgrove Grindability Index Tester
1.Main Introduction:
Hardgrove Grindability Tester is a special tester for testing the grindability of sof coal and blind coal.
It takes grinding law as the theoretical basis (the energy consumed in coal grinding is proportional to the new surface area of coal dust).
Under the conditions specified in GB2656/T1998 "Coal Grindability Index Determination Methods" (Hardgrove method) ,the tester would grind,sieve and weigh the prepared coal sample,later you can get the grindability index from the index charts of standard coal sample.If the index is biger,then the sample coal is easier to be broken.
2.Features:
Auto-lifting of grinding bowl, auto-loading, auto-counting of revolution
The tester will stop automatically when the counter shows 60 revolutions.
Built-in program of linear regression correction curve, the calibration realizes automatic calculation
The emergency stop is available if malfunction happens,and the revolutions will be accumulated after restarting.
3.Technical Parameters:
Model | AMS-HGI |
Power | 90w |
Working Revolution | 60±0.25r |
Spindle Rotate Speed | 20r/min |
Vertical Grinding Pressure | 284±2N |
Weight | 85kg |
Dimension | 360*425*440mm |
