North Benz 6.3 Ton Crane Truck Crane Factory Directly Sales

Truck model

DLQ

Chassis model

ND1160W241D

Weight parameter

(kg)

Payload

15000kg

Outline size (mm)

8800X2470X3250

Curb Mass

8000kg

Container(m3)

8m3-10m3

Total Mass

23000kg

Wheelbase (mm)

4800

Engine

Engine Model

WD615.56

Displaceme(L)

9.726L

Power(kw)

193

Horse power(hp)

262hp

Engine

Manufacture

Weichai power

Fuel type

Diesel oil

Engine type

Water-cooling,supercharged 6-cylinder inner-cooling diesel engine

Chassis description

Max speed

(km/h)

85

Track span (mm)

Front tread

1940

Drive type

4x2

Rear tread

1860

Wheelbase(mm)

4800

Reaching out of

vehicle (mm)

Front overhang

1245

Front axle(T)

5T

Rear

Overhang

1405

Rear axle(T)

10T

Driving angle (°)

Approach angle

34°

Leaf of spring

9/11+8

Departure angle

20°

Tire specification

12.00-20

Air-conditioner

Choose to fix

Steering gear

Dual-armed steering wheel,powering steering,6 gear mechanical drive

Clutch

Diaphragm clutch,hydraulic remote control,pneumatic serveo

Transmission

6 gear mechanical drive transmission

Breaking system

Split air braking system,spring breaking,exhaust breaking

Cab description

Non-longheaded one and half row cab,whole metal enclosed,reversible cab, With ergonomic mechanical damping suspension seat,choose to fix CD palyer or radio player

Special function

Of Crane

Crane model

SQ5SK2Q/SQ5SK3Q

Max Lifting Capacity(kg)

5000

Max Lifting Moment(T.M)

12.5

Recommend Power(KW)

18

Max Oil Flow of Hydraulic

System(L/Min)

32

Max Pressure of Hydraulic System(Mpa)

18

Oil Tank Capacity(L)

90

Rotation Angle

360

Crane Weight(kg)

2074/2170

Installation Space(mm)

900
