EB-105 CE made in china factory direct high efficiency oil burner

Specifications

waste oil burner EB-105

Features:

1.Various fuels are applicable, e.g. used engine oil, used crankcase oils, used Hydraulic oil, used synthetic oils, waste machine shop cutting oil, waste mineral spirits solvent, waste grades #1, #3, #4 heating oils, waste mixed heavy oil etc., as well as regular oils, such as diesel, etc.

2. Automatic ignition, workers nursing unnecessary;

3. Flame adjustable freely by air-inlet controlling;

4. All parts tested thousands of times and improved to be of good quality and reliable.

5. All errors readable from the front panel thus EMPIRE burner is just “Smart Burner”!

6. Complete fuel burning ensures very low emissions, environmentally –friendly.

7. 220V/50Hz & 110V/60Hz both available

8. Specifications

Oil consumption:------------------------------------------------------2 - 5 (KG/Hour)

Output heat power---------------------------------------------------24-59 (KW)

Output heat: 20,400-52,000(KCal/H) / 80,000-200,000(BTU/H)

Nozzle(s)----------------------------------------------------------------- 1 x 1.0 (mm)

Distance from fire gun to flange---------------------------------173mm

Blast tube Diameter-------------------------------------------------- 100/114mm

Distance of screw bore in the flange--------------------------160x160(mm)/6.3x6.3inch

Compressed Air Pressure------------------------------------------0.05-0.1MPa

Pumping system including: a Pump, an Electric Motor, a Stainless Steel floating ball,

filters, etc

Related Products

Waste oil boiler(click product name)

Waste oil heater(click product name)

Waste oil heater(click photo)

 standard for sea transportation

1.one year waranty,during the period spare part will supplu free if you pay for shipping

2.service for ever
