Product Details
| Place of Origin | Shanghai, China | Brand Name | OEM | |
| Model Number | SC Simlex adapter |
Product Description
SC/PC Mutimode Simplex Fiber adapter for telecommunication
Features :
Insertion loss: Less than 0.2dB
Return loss: 45dB/PC, 55dB/UPC, 65dB/APC
Retentivity:200-600g
Repeatability (1,000 times): Less than 0.2dB
High precision alignment
Compact design
Various housing materials and sleeve materials
Nickel plated brass body
Telcordia, ANSI, TIA/EIA, NTT and JIS compliance
Availability :
Housing: Square or D-type
Sleeve: Zirconia
Applications :
Telecommunication networks
Test equipment
Local area networks (LANs)
Data processing networks
CATV
Patch panel, optical fiber distribution frame
| Item | SM(UPC) | SM(APC) | MM(PC) |
| Insertion loss(dB) | ≤0.3 | ≤0.3 | ≤0.3 |
| Repetitiveness(dB) | ≤0.1 | ≤0.1 | ≤0.1 |
| Interchangeability(dB) | ≤ 0.2 | ||
| Plug time(times) | 500-1000 | ||
| Operating Temperature(°C) | -25~85 | ||
| Humidity | 95% | ||
| Sleeve Material | Zirconia | Zirconia | Phosphor |
| Bronze | |||
