bitzer compressor 4g-30.2
- sahnghai
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | CICEL | |
| Model Number | CZ-1300ION | Type | Other, Powder Coating Booth | |
| Certification | CE |
Product Description
Specifications
pvd vacuum coaters1,good abrasion resistance
2,Easy to operate
3,Nice after-service support
4,environment-protect
1) Technical index.
Ultimate vacuum: (after roasting) vacuum degree limit ≤6×10-4Pa
Work vacuum: The short time exposition atmosphere starts to pump air, vacuum degrees≤6×10-3Pa in 15 minutes.
Both sides of vacuum chamber, installed with 12sets of electric arc target (Φ100mm).
Gas supply system: adopt four MFC supply.
Power supply voltage: AC380V±5%. 50HZ;
Water pressure: 0.2-0.3MP/CM2.
2) Configuration of machine
Part name | Specification | Supplier | Quantity | |
Chamber size | Ø1300mm×H1500mm | CICEL | 1set | |
Lining board | 1mm stainless steel | CICEL | 1set | |
Workpiece steady | custom-made | CICEL | 1set | |
Rotation system | Frequency regulation | CICEL | 1set | |
Bias power supply | 30kw | GUANGDONG | 1set | |
arc power supply | 200A | GUANGDONG | 12sets | |
Ti target | Ø100 | CICEL | 12pcs | |
Flow value | D07-7C series | BEIJING | 4sets | |
Flow control instrument | D07-7C series | BEIJING | 1set | |
Gas-pressure gauge | international standard | CICEL | 1set | |
Vacuum measurement | ZDF—5227 | SICHUAN | 1set | |
Heating pipe | 9KW | CICEL | 12sets | |
valve | Main valve | GDQ-800 | CICEL | 1set |
Rough valve | GDQ-200 | CICEL | 1 set | |
Front valve | GDQ-150 | CICEL | 1 set | |
vacuum system | Diffusion pump | KT-800 | CICEL | 1set |
Mechanical pump | 2X-70 | SHANGHAI | 2sets | |
Roots pump | ZJY-600A | SHANGHAI | 1set | |
Holding pump | 2X-15 | SICHUAN | 1set | |
Electrical appliances | Standard equipment | Omron&Delixi | 1set | |
HMI | 10.4 inch touch screen | Xinjie | 1set | |
Control system | PLC programming | Xinjie | 1set | |
Pumping speed | 5×10-²≤5min | Idle oven |
| |
