40KW 50KVA Weifang Diesel Geneartor Sets

Generator sets

Mode

GF2-40KW

 Max.Output (KW)

40.1

 Rated.Output (KW)

36

 Freuency (HZ)

50

 Voltage (V)

220/380

 Rated Current (A)

72

 Power Factor

0.8

 Starting way

Electric start

 Panel shape

Universal panel

 Frameware shape

Open type/Silent type

 DC output

Without

 Fuel Tank(L)

Withtout

 Fuel consumption (g/kW.h)

225

Continuing running time(Under rated output)

Available for continuing running

Dimension (mm)

1780X650X1800

Net.weight (kg)

800

Accessory tools

Tool box/ manual /wear parts

Engine

 Engine brand

Shangdong weifang

Engine model

4100ZD

Max.output [Kw(r/min)]

40.1

 Adjusting system

Machinery

Noise Level(Null-Full)(A)/7m 65-75

110

 Cylinder type

Four Cylinder, OHV,4-Stroke,water cooled

 Bore×Stroke (mm)

100*65

 Compression

17:1

 Displacement (ml)

400

 Speed (r/min)

1500

Lub Mode

CD or upward or SAE10W-30,15W-40

  Lub tank (L)

25

 Battery capacity (v-Ah)

12V-105A

Cooling way

Water-cooled

Lub way

Pressure splashing compound

heat radiation water tank (L)

100

 Fuel type

Diesel:0#(Summer)-10#(Winter)-35#(severe cold)

Alternator

Alternator Manufacture

Fuan Raygong

 Model

TFWS-40KW

 Alternator type

Brushless

Phase

Three phase

 Insulation level

F

Pole

4

Magnetization way

Brushless self-excitation

Output socket

Without

 Output wiring terminal

Yes
