Home > Products > Hot-selling > Sae 1020 Carbon Steel Bar, Steel 1020, 1020 Steel
Sae 1020 Carbon Steel Bar, Steel 1020, 1020 Steel
- Shenzhen port China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Free Sample Aisi 4140 Carbon Alloy Steel Round Bars, 4140 Alloy Steel, Steel Aisi 4140
-
4140 Alloy Steel, 1.7225 Steel Material, SCM440 Bahan Setara
-
Steel Din 1 7225, SCM440 Bahan Setara, 4140 Alloy Steel Round Bar
-
Factory Price H13 Tool Steel, H13 Hot Die Steel, H13 Material
-
Forged Connecting Rod SAE AISI 4340 Steel Bars Price
-
S136 Weight of 12mm Thick Steel Plate
Product Details
| Steel Grade | 1020 | Standard | AISI, ASTM | |
| Dimensions | Diameter 10~16000mm | Place of Origin | Guangdong, China | |
| Brand Name | YT | Model Number | sae 1020 carbon steel bar, steel 1020, 1020 steel | |
| Technique | Hot Rolled | Application | Structural Steel Bar | |
| Alloy Or Not | Is Alloy | Special Use | Mold Steel | |
| Type | Carbon Steel Bar |
Product Description
sae 1020 carbon steel bar, steel 1020, 1020 steel
Who are we?
•1995.10 Established tool steel Plus workshops,beginning make the
mould steel cutting process
•2001.7 Changed to limited liability company, have 8 set
semi-automatic Bandsaw Cutting machinery and 3 set planing machine.
•2004.6 All Bandsaw Cutting machinery update to CNC Machinery,1 set
large precision grinding machine and 2 set small grinding is was
introduced and purchase a set Gantry Milling
•2009.5 Establish cooperation with Changcheng Special Steel Co.,Ltd, FUSHUN special steel and BaoSteel. as the specified distributor for special steel.
•2010.2 Start International trade
•2012 Through Alibaba certified high quality suppliers
•2013 and 2014 finished the company new Shares system , Customers in more than 40 countries around the world

AISI carbon steel 1020 price, 1020 cold rolled steel
1020 steel stockholders and suppliers, delivering to the whole of the China. AISI 1020 is a low hardenability and low tensile carbon steel with Brinell hardness of 119 – 235 and tensile strength of 410-790 MPa. It has high machinability, high strength, high ductility and good weldability. It is normally used in turned and polished or cold drawn condition. Due to its low carbon content, it is resistant to induction hardening or flame hardening. Due to lack of alloying elements, it will not respond to nitriding. However, carburization is possible in order to obtain case hardness more than Rc65 for smaller sections that reduces with an increase in section size. Core strength will remain as it has been supplied for all the sections. Alternatively, carbon nitriding can be performed, offering certain benefits over standard carburizing.
AISI 1020 steel can be largely utilized in all industrial sectors in order to enhance weldability or machinability properties. It is used in a variety of applications due to its cold drawn or turned and polished finish property.
We welcome export enquiries for 1020 carbon steel. Contact our sales office and consult our shipping policy for further details.
Grade AISI DIN JIS BS NF GB
1020 1.0402 S20C 050A20 XC18 20
| Analysis |
|
| Form of Supply | YAOTENG Steel are 1020 steel stockholders of round bar. Diameters can be supplied as full bar lengths or cut pieces. 1020 ground steel bar can be supplied, providing a quality alloy steel precision ground bar to tight tolerances. Contact our experienced sales team who will assist you with your AISI 1020 carbon steel enquiry. |
Plate | Diameter |
| Applications | AISI 1020 steel is used in case hardened condition. The applications of AISI 1020 steel are: • It is used for simple structural application such as cold headed bolts. • AISI 1020 steel also finds use in the following components: • axles • general engineering parts and components • machinery parts • shafts • camshafts • gudgon pins • ratchets • light duty gears • worm gears and • spindles |
| Forging | Preheat the steel carefully, then raise the temperature to 1150-1200°C for forging. Do not forge below 850°C. |
| Annealing | AISI 1020 steel is heated at 870°C - 910°C followed by holding for certain time until the temperature remains constant all over the section. It is then cooled in a furnace |
| Stress Relieving | AISI 1020 steel is heated to 650°C - 700°C followed by holding until the temperature remains constant all over the section and soaking for 1 hour per 25 mm of section. It is then cooled in still air. |
| Hardening | After performing the core refining process, it is re-heated to 760°C - 780°C followed by holding until the temperature is consistent all over the section. It is then quenched in water. |
| Tempering | AISI 1020 steel is re-heated at 150°C - 200°C followed by holding for certain time until the temperature remains constant throughout the section. It is soaked for 1 hour per 25 mm of section and then cooled under normal atmosphere. By performing the tempering process, the toughness of the case will be improved and grinding cracks will be reduced |
Physical Properties
Mechanical Properties | Metric | Imperial |
Hardness, Brinell | 111 | 111 |
Hardness, Knoop (Converted from Brinell hardness) | 129 | 129 |
Hardness, Rockwell B(Converted from Brinell hardness) | 64 | 64 |
Hardness, Vickers (Converted from Brinell hardness) | 115 | 115 |
Tensile Strength, Ultimate | 394.72 MPa | 57249 psi |
Tensile Strength, Yield | 294.74 MPa | 42748 psi |
Elongation at Break (in 50 mm) | 36.5 % | 36.5 % |
Reduction of Area | 66.0 % | 66.0 % |
Modulus of Elasticity (Typical for steel) | 200 GPa | 29000 ksi |
Bulk Modulus (Typical for steel) | 140 GPa | 20300 ksi |
Poissons Ratio | 0.290 | 0.290 |
Charpy Impact | ||
@Temperature -30.0 °C/-22.0 °F | 16.9 J | 12.5 ft-lb |
@Temperature -18.0 °C/-0.400 °F | 18.0 J | 13.3 ft-lb |
@Temperature -3.00 °C/26.6 °F | 20.0 J | 14.8 ft-lb |
@Temperature 10.0 °C/50.0 °F | 24.0 J | 17.7 ft-lb |
@Temperature 38.0 °C/100 °F | 41.0 J | 30.2 ft-lb |
@Temperature 65.0 °C/149 °F | 54.0 J | 39.8 ft-lb |
@Temperature 95.0 °C/203 °F | 61.0 J | 45.0 ft-lb |
@Temperature 150 °C/302 °F | 68.0 J | 50.2 ft-lb |
Izod Impact | 125 J | 92.2 ft-lb |
Shear Modulus (Typical for steel) | 80.0 GPa | 11600 ksi |
| Heat Treatment | Heat treatment temperatures, including rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each 1020 steel component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities. Please consult your heat treatment provider for full guidance on heat treatment of alloy steel. |
|
| Quality Assured Supply | 1020 Carbon steel is supplied in accordance with our ISO 9001 : 2008 registration |
.
