1216 Pex al Pex Natural Gas Pipe Yellow Color

1216 pex al pex natural gas pipe yellow color

pex pipe parameters:

Thermal conductivity ------------------------------------- 0.45W/m.k

Thermal Expansivity -------------------------------------- 2.5 x 10^-5 m/m.k

Bend Radius -------------------------------------------------- ≥ 5D (D: Tube Diameter)

Operating Temp Range --------------------------------- -40 - +95°c

Working Pressure ------------------------------------------ ≤ 1.25Mpa

Radial Force Penstock ---------------------------------- 2400 - 3320N

Bursting Strength ------------------------------------------ 5.5 - 8Mpa

pex pipe profile

PEX-AL-PEX pipes, or AluPEX, or PEX/Aluminum/PEX, are made of a layer of aluminum sandwiched between two layers of PEX. The metal layer serves as an oxygen barrier, stopping the oxygen diffusion through the polymer matrix, so it cannot dissolve into the water in the tube and corrode the metal components of the system. The aluminum layer is thin, typically 1 or 2 mm, and provides some rigidity to the tube such that when bent it retains the shape formed (normal PEX tube will spring back to straight). The aluminum layer also provides additional structural rigidity such that the tube will be suitable for higher safe operating temperatures and pressures.

Application

1) Potable water For cold and warm water installations

2) For rainwater utilization systems

3) For compressed air plants

4) For swimming pool facilities

5) For solar plants

6) For agriculture and horticulture

7) Heating pipes for residential housing

8) For industry

Pictures

The pex al pex pipe for gas are very stable,so can hot welded conection by heating machine.We also supply hot welding pipe fittings

Our procedure line
