medical diagnostic x-ray equipment,medical film x ray film,medical laser printing film

Specifications

Features :
This product have image layer and protect layer on different side of bluish polyester bases, and there are no sensitive silver halide in both layer. The film is fit for thermal printer to print digital image which was processed and stored in the computer, to attain the enhanced x-ray image quality. It is environmentally friendly since the process procedure was saved and free of the Chemicals. The product features low fog, high sharpness, high max density, bright tone, and conveniently to use.

uses: It can be used directly in the Fuji 2000 ,Lucky 1000,AGFA 5302,5300,5500 thermal printer.It need to test to ensure a best condition when it is used in other brand printer.
Safe light
It can be processed under room light since the film was not sensitive to light.
Processing
The product can be directly printed by thermal printer which pointed by Lucky to get ideal image. The print conditions should be tested when use the film in other printer.
Storage
Please store the film in cool and dry place with out dust. Keep away from direct sunlight, acid or alkaline gas. Details as follows:
1. Temperature and humidity: temperature 10°C-23°C, humidity 30%-65%RH, keep away from the heat resource.
2. Gas: There are no hydrogen sulfide, ammonia, sulfur dioxide, formaldehyde, and any other alkaline gas, etc.
3. Pile: Please keep film upright to avoid the bad influence cause by pressure.
Period of validity
The period of validity is 18 months under above conditions.
Conditions of usage
The best condition of usage as following:
Temperature 18°C-24°C, humidity 50%-65%RH.
Note:

1. Store the film under the conditions specified above.

2. Take the film out of the cool place and place the film with the package in the place where the film will be used for at least 4 hours, to avoid the steam concentrate on the film and damage the film.
3. Handle the film should be careful, dont crash, fold, distort and rub the film, dont touch the film with wet hand.

4. Handle the waste film should obey the local law and regulations.

Package and size

The production process:
