Lowing Water Temperature Machine Small Water Chiller
- Ningbo China
You May Like
Product Details
| Condition | New | Type | Water-Cooled | |
| Place of Origin | Zhejiang, China | Brand Name | XINHE | |
| Model Number | XCW-xxS/D | Cooling Capability(kw) | 29.5kw to174kw | |
| Voltage | 220V or 380V | Weight | 150kg to 1400kg | |
| Certification | CE, Other, CE, ISO9001:2000 | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Water chiller :1.Used for Injecion molding machine ,plastic ,etc
2.Hermetic scroll/Piston type
3.Simple operate .
I. Instruction of Water chiller :
1.Compressors adopt the new and famous brand compressors imported from Europe, Japan and the United States with the feature of environmental protection, energy saving and durability.
2. It can be placed directly at working site to avoid the cooling loss caused by far distance;
3. Evaporator use the efficient and internal thread tube having the "U" shape design, small size, high efficiency and easy cleaning & maintenance;
4. Best suited for high-temperature and strong corrosion& severe pollution industries such as chemical, surface treatment, the plastic industry, etc.
II. Technology parameter of Water chiller :
Models | Cooling | Input | Compressor | Evaporator | Condenser | The machine |
Capacity | Power | Flow water | Cooling water | size | ||
The models below include 1 compressor | ||||||
XCW-08S | 25,370kcal/hr | 8.2kw | 6.81kw | 4.2kw | 5.5kw | 1400*750*1200mm |
XCW-10S | 31,390kcal/hr | 10.4kw | 8.8kw | 5.5kw | 7.2kw | 1400*750*1200mm |
XCW-12S | 37,496kcal/hr | 12.6kw | 10.8kw | 6.6kw | 8.2kw | 1400*750*1200mm |
The models below include 2 compressors | ||||||
XCW-16D | 49,192kcal/hr | 16.2kw | 13.8kw | 7.8kw | 10.6kw | 1500*800*1250mm |
XCW-20D | 62,780kcal/hr | 20.8kw | 17.5kw | 11.2kw | 13.8kw | 1650*800*1350mm |
XCW-25D | 75,164kcal/hr | 25.6kw | 21.8kw | 13.4kw | 17.8kw | 1650*800*1350mm |
XCW-30D | 97,180kcal/hr | 32.6kw | 27.5kw | 16.6kw | 20.6kw | 2100*1000*1350mm |
XCW-40D | 124,700kcal/hr | 41.8kw | 35kw | 21.2kw | 28.5kw | 2200*1150*1500mm |
XCW-50D | 149,640kcal/hr | 51.6kw | 43.5kw | 26.5kw | 36.3kw | 2200*1150*1500mm |
Note: | ||||||
1.Rate cooling capacity is based on the following parameter :evaporating temperature:10°C,Condensing temperature:43.3°C. | ||||||
2.Main Voltage :3p-380V/50HZ and 3P-220V-50HZ/60HZ | ||||||
3.Refrigerant :R22 | ||||||
III.Main parts of Water chiller :
IV.Certificates of Water chiller :
V.Widely application of Water chiller :
It's widely used for Injection molding machine,plastic ,leather ,chemical factory ,and many fileds ,which need to low the water temperature .
