China Super Capacitor 2.7V 1.0F
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Amazing | |
| Model Number | MZ-5R5-103 | Type | Other, Super Capacitor, Super Capacitor | |
| Application | General Purpose | Package Type | Through Hole | |
| Capacitance | 1.0F of super capacitor | Rated Voltage | 2.7V of super capacitor | |
| Operating Temperature | -25C to +70C of super capacitor |
Product Description
Specifications
1.China capacitor 5.5V 1.0F super capacitor2.Rechargeable button cell battery with high voltage
3.Fast charging
China capacitor 2.7V 1.0F super capacitor
Features of made in China super capacitor :
1. high power performance,
2. over 100,000 duty cycles,
3.low ESR,long voltage holding,
4. coin cell,
5.low leakage current,
6. both positive&negative lead tabs extend to one direction.
Applications of made in China super capacitor :
Electronic circuits such as memmory back up,water meter,toys and etc.
Advantage of super capacitor :
1. 7V & 5.5V
2. Light Weight, high energy density
3. Super long working life
4. Wide temperature range from -25 °C to +75°C
5. Excellent charge and discharge characteristics
6. Low equivalent resistance in series
General Specification of made in China super capacitor .
Item | Specification/Condition | |
01 | Part No. | FH-SC5R5-105VY |
02 | Rate discharge capacitance (F 25°C Voltage drop=3V-2.5V I=0.01A) | 1.0 |
03 | Capacitance tolerance | -20%~+80% |
04 | Rated Voltage U0 (V) | 5.5 |
05 | Operating temperature range | -20°C~70°C |
06 | MAX.ESR(mΩ 1KHz) | 6.0 |
07 | Dimension(mm ΦD×L) ±2 | 19*5.1 |
08 | Down-lead diameter(mm p) | 5 +/-0.5 |
09 | Cycle life Expectancy | After nominal voltage,100,000 times charge-discharge circleCapacitance drop/Capacitance≤30% of the initial value ,ESR≤4 times of the specified value(25°C). |
2. ) Environmental Specification of made in China super capacitor .
Item | Specification/Condition | |
01 | Temperature characteristics | +70°C,Capacitance drop/Capacitance≤30% of the initial value,ESR≤specified value (25°C) -25°C,Capacitance drop/Capacitance≤50% of the initial value,ESR≤4 times of specified value(25°C) |
02 | High temperature load characteristics | After +70°C±2,nominal voltage,1000h,Capacitance drop/Capacitance≤30% of the initial value,ESR≤4 times of specified value(25°C). |
03 | High temperature without load characteristics | Same with the High temperature load characteristics |
04 | Humidity Resistance | After +40°C±2, 90--95%RH,240h,Capacitance drop/Capacitance≤30% of the initial measured value, IL≤2 times of specified value(25°C),ESR≤4 times of specified value(25°C). |
