15 ton amphibious excavator made in china
USD $100,000 - $200,000
/ Set
1 Set(Min.Order)
- 10 Set / Sets per Month
- shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Anhui, China | Brand Name | SINOXIA | |
| Model Number | SX150SD | Condition | New | |
| Moving Type | Other, pontoon | Operating Weight | 15000kg | |
| Bucket capacity | 0.25m3 | Maximum Digging Height | 8443mm | |
| Maximum Digging Depth | 5879mm | Machine Weight | 15000kg | |
| Max Digging Radius | 8772mm | Rated Speed | 30km/h | |
| Certification | ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
| Type of the machine | HK150SD hydraulic crawler excavator with extendable chasis | |
| Operating weight | 15000KG | |
| Standard bucket capacity | 0.25m³ | |
| Boom length | 4500mm | |
| Arm length | 3000mm | |
| Chains | 2 | |
| Engine model | Yammar 4TNV98T | |
| Type | inter-cooled turbo | |
| Power | 56.5kW/2200rpm | |
| Max.torque | 301N m / 1650rpm | |
| No.of cylindar | 4 | |
| Displacement | 3.319L | |
| Type | Variable plunger pump | |
| Max.displacement | 90cm3/r | |
| Working pressure | 26.5Mpa | |
| Slew motor | fixed plunger | |
| Travel motor | variable plunger | |
| Slew speed | 12rpm | |
| Min.slew radius | 2257mm | |
| Max.travel speed high/low | 3.79/2.33km/h | |
| Gradeability | 35° | |
| Tracktive effort | 112.2kN | |
| Max.digging force of bucket | 49kN | |
| Max.digging force of arm | 43.4kN | |
| Ground pressure | 0.13kg/cm2 | |
| Fuel tank capacity | 300L | |
| Hydraulic tank capacity | 210L | |
| Item | Standard(mm) | |
| Length of pontoon | 6640 | |
| Ground clearance of platform | 1474 | |
| Overall height | 3294 | |
| Boom transport height | 3294 | |
| Overall length | 9009 | |
| Rear swing radius | 2130 | |
| Track gauge | 2050-3100 | |
| Overall width | 3500-4548 | |
| Width of pontoon | 1298 | |
| Min.ground clearance | 717 | |
| Height of pontoon | 1420 | |
| Width of upper structure | 2207 | |
| Item | Standard(mm) | |
| Max.digging reach | 8996 | |
| Max.digging reach on ground | 8772 | |
| Max.digging depth | 5879 | |
| Max.vertical digging depth | 4796 | |
| Max.digging height | 8443 | |
| Max.dumping height | 6457 | |
| Min.front slewing radius | 3524 | |
