Carbonated Drink Filling Machine

Specifications

    This machine is core machine in beer/carbonated drinks production line. It is for fill and seam of beer and other carbonated soft drinks(aluminum can/pet can), like cola,soda,energy drinks and so on.

     It adopts isobaric pressure filling principle. The main electric elements adopt “Siemens” PLC, “Delta” frequency converter, “Omron” proximity sensor, and “Siemens” analog output.

    The user could setup the production speed on touch screen. Machine alarm automatically of all common malfunctions and show the cause and position of malfunction, PLC detect and decide to continue or stop the machine according the level of malfunction.

    It is quality seaming, high speed, running steady, good looking and easy to use and maintenance.

Upgrade capping part:

1.     More reasonable and beautiful overall structure

2.     Obvious bigger seaming head, adopt heavy bearing which prolong the seaming cam        service, the normal service time prolong 5 times.

3.     Twin shafts structure: The first seaming roll and the second seaming roll are separated. User could adjust and control the seaming rolls separately.

4.     The rotation direction is anticlockwise direction in seaming process, the capped cans leave the capping part automatically as its direction to avoid jam and scratch.
