soda water machine
- ningbo
- T/T
You May Like
Product Details
| Condition | New | Application | Beverage | |
| Packaging Type | Cans | Packaging Material | Wood | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V | Power | 5.5kw | |
| Place of Origin | Zhejiang, China | Brand Name | weichi | |
| Model Number | DGD2004 | Dimension(L*W*H) | 3400mm*1950mm*1900mm | |
| Weight | 5500kg | Certification | ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Can counterFrequency drive
No-Can-No-Cover
Touch screen operation
30 years can packing experience
This machine is suit for fill and seam of beer and other carbonated soft drinks, like cola,soda,energy drinks and so on. It adopts isobaric pressure filling principle.The main electric elements adopt “Siemens” PLC, “Delta” frequency converter and “Omron” proximity sensor, “Siemens” analog output.
The user could setup the production speed on touch screen. Machine alarm automatically of all common malfunctions and show the cause and position of malfunction, PLC detect and decide to continue or stop the machine according the level of malfunction.
Other advantages:
1. Equip with remote computer control system;
2. Adopts import frequency converter, adjust filling and seaming speed at will;
3. Equip with steam jet device according the customer requirement;
4. Filling quantity even and easy for adjustment;
5. Special filling valve is easy for clean.
Technical Parameter: | |
Item No: | DGD2004 |
Filling heads: | 20 |
Capping heads: | 4 |
Capacity: | 30~150cans/min |
Can Diameter: | Φ52.5~Φ99mm |
Can Height: | H122~H160mm |
Power: | 5.5Kw |
Voltage: | 380V 50HZ 3 phase+N+G |
Weight: | 4000KG |
Dimension: | 3400mm*1950mm*1900mm |
