15-2700ml per min CT3001F Intelligent Dispensing Micro Gear Pump
- Dalian
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
0.7-23LPH, 16-1.5bar, Phosphate Metering Pump for Boiler
Quality Choice
-
0.7-23LPH, 16-1.5bar, Made in China Caustic Soda Metering Pump
-
0.7-23LPH, 16-1.5bar, High Quality Phosphate Dosing Pump for Boiler
Quality Choice
-
0.7-23LPH, 16-1.5bar, High Quality Ammonia Metering Pump
-
0.7-23LPH, 16-1.5bar, High Quality Hydrazine Metering Pump for Boiler
-
0.7-23LPH, 16-1.5bar, High Quality Caustic Soda Dosing Pump
Product Details
| Place of Origin | Hebei, China | Brand Name | Lead Fluid | |
| Model Number | CT3001F | Theory | Rotary Pump | |
| Structure | Gear Pump | Usage | Other, Transferring, dispensing | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, Electricity | Pressure | Other, Low Pressure, up to 8 bar | |
| Application | Metering |
Product Description
15-2700ml per min CT3001F Intelligent Dispensing Micro Gear Pump
1. Mutiple option of pump heads
2. Preferable for high viscosity, high pressure liquid
3. No pulsation, low noise
4. Magnetic coupling, easy to maintain
5. Brushless servo drive, high efficiency, easy for maintenance
6. Color LCD display, touch screen operation
7. Flow rate display & controllable
8. Mutiple work mode
9. Flow calibration wizard, ensuring the accuracy
10. Intelligent temperature control function
11. External control: signal control, physical isolation, analog control
12. RS485 communication, supporting the MODBUS protocol
13. Stream line plastic shell
14. Wide range of power input: AC 90-264V 50HZ/60HZ
CT3001F is a high performance, low noise of micro gear pump, brushless servo motor, stainless steel, magnetic drive pump head can be realized constant transfering fluid without pulsation.Streamline drives use plastic shell, color LCD display, touch screen operation, can be easily set parameters.A variety of work mode, flow display, and are suitable for all kinds of LAB areas.A variety of external control way, convenient to use with other devices,and the MODBUS protocol communication, simplify the difficulty of system development.
Technical Parameters for CT3001F Intelligent Dispensing Micro Gear Pump:
Suitable pump heads | MG204,MG209,MG213 |
Main function | Keypad to control start/stop, direction, full speed, memory (power lost memory);Foot switch control external control start/,stop, external control direction, with physical isolation, level 5 v / 12 v / 24 v input is optional;0 to 5 v / 0 to 10 v / 4-20 mA speed control optional;Transfer mode, fluid volume distribution mode, time distribution mode, copy distribution mode. |
Communication function | RS485,Support Modbus communication protocol |
Display function | True color touch screen display |
Direction control | CW&CCW |
Main Features of CT3001F Intelligent Dispensing Micro Gear Pump:
Flow range | 15-2700ml/min |
Speed range | 50-3000RPM |
Speed resolution | 1rpm/min, accuracy:0.5% |
Dispensing time | 0.1-99.99s |
Interval time | 0.1-999.9s |
Dispensing time | 0-999 |
Control way | Keypad + Touch screen |
Display way | 65565 LCD |
Power supply | AC 90-264V 50Hz/60Hz |
Power consumption | <50W |
Working environment | Working environment :0-40℃ Relative humidity <80% |
Dimension | 342*198*182mm |
Drive weight | 3.5kg |
IP standard | IP31 |
Pump Head Models:
Pump head model | Gear material | Transfer pressure (MPa) | Flow rate (ml/min) | Fluid temperature(℃) |
MG204XD0PT00000 | PEEK | 0.8 | 15-900 | -45~120 |
MG209XD0PT00000 | PEEK | 0.8 | 30-1800 | -45~120 |
MG213XD0PT00000 | PEEK | 0.3 | 45-2700 | -45~120 |
MG204XD0TT00000 | PTFE | 0.8 | 15-900 | -45~50 |
MG209XD0TT00000 | PTFE | 0.8 | 30-1800 | -45~50 |
MG213XD0TT00000 | PTFE | 0.3 | 45-2700 | -45~50 |
Photo of CT3001F Intelligent Dispensing Micro Gear Pump
Dimensions:
Carton packaging.
Quality is always our top priority in our business. We have excellent quality control system and professional quality engineers. We believe the best way to avoid quality problems is not to let any product with quality issue out of the factory. At the same time, we provide 1 year quality guarantee(from B/L date).
