Automatic glass bottle 3 in 1 filling equipment/line for Vodka

FOB Price

US$ 5,000 - 50,000 / Set

1 Set(Min. Order)

Port shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Beverage
Packaging Type	Barrel, Bottles, Cans	Packaging Material	Plastic, Wood
Automatic Grade	Automatic	Driven Type	Electric
Voltage	220V/380V	Power	as required
Place of Origin	Jiangsu, China	Brand Name	Wanjin
Model Number	RXGF	Dimension(LWH)	by capacity
Weight	by capacity	Certification	CE
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

1.PLC control
2.No leak,NO drop
3.fill accurate,material:SUS304
4.capacity:2000-20000b/h

Automatic glass bottle 3 in 1 filling equipment for Vodka:

We are the automatic juice packaging and bottling machine manufacturer from China.

Features:

1.This machine is used to fill beer,wine,and other kinds of juices.

2.All the machine part which contact with liquid is high quality stainless steel 304. The relative fittings are from international famous brand.

3.The automatic juice packaging and bottling machine was equipped with suspension type air conveyor and frequency control of motor speed.

4.This machine is comprised of rinsing, filling and capping system. Rinsing: grip the bottle neck, rotate filling plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely. Filling: hot filling with holding bottle neck; the special backflow type of the filling valve can avoid leakage after filling and also control liquid level accurately. Capping: magnetic torque bottle holding type can minimize the cap damage rate and make the capping performance the best.

5.This machine owns the reasonable, stable and safe design. Under the condition that the bottle neck size is the same, only the output star wheel needs to be changed if bottles are different. It improves the efficiency a lot.

Main Technological data:

MOdel	RXGF	RXGF	RXGF	RXGF	RXGF	RXGF
Production capacity (500ml b/h)	3000-4000	4000-6000	6000-10000	10000-15000	15000-20000	20000-24000
Filling precision	±2mm(Liquid Level)
Suitable cap shape	Bottle Diameter:50-100 Hight:150-310
Polyester bottle standard(mm)	Plastic Screw Cap
Water pressure of washing (Mpa)	0.2-0.25(Mpa)
Gas consumption(m³/min)	0.1	0.1	0.4	0.5	0.5	0.6
Power(KW)	4.4	4.4	5.2	6.2	7.8	10
Weight(kg)	2200	2800	4500	6000	7000	9500
Dimensions(LWH)(mm)	223016302250	236018302250	290022002250	388022002250	370030002350	450035002400

Product view:
