Product Details

Place of Origin	China	Brand Name	HUIFENG
Model Number	pvc foam sheet	Material	PVC
Thickness	1-40mm	Size	12202440,15603050,2050*3050mm

Product Description

Specifications

Construction pvc foam sheet
1.Size: 1220*2440,1560*3050,2050*3050mm
2.Thickness: 1-40mm
3.Density: 0.35-0.9
4.Factory price

Product Name	PVC foam sheet
Place of origin	Shandong China
Main material	PVC powder
Size	12202440,15603050,2050*3050mm, or as your requirements.
Thickness	1-40mm, usually Free Foam (1~10mm) & Celuka (3~20mm)
Density	0.35-0.9 g/cm3
Color	White
Features	1)Light weight,waterproof, Antiflaming and self-extinguishing,etc 2) Sound insulation, heat insulation , noise absorption, heat preservation and anti-corrosion 3) Tough, rigid with a high impact strength,not easy to age and can keep its color for longtime 4) Easy to clean and maintain 5) Environmental-friendly green healthy materials
Service	OEM
MOQ	100 pieces
Payment	30% deposit, balance before loading, L/C
Dilivery time	15days after receiving your deposit
Package	nude package, PE film,pallet
production capability	1000 tons / month
Factory location	Economic Development Zone, Malus heated industrial park,

Technical Properties

Properties	Test	Unit	Value
Physical
Density	DIN 53479	g/cc	0.55 - 0.70
Hardness	DIN 53505	Shore D	≥ 42
Water Absorption	DIN 53495	%	≤ 1.0
Mechanical
Tensile Strength*	DIN 53455	MPa	≥ 15
Elongation at Break**	DIN 53455	%	≥ 15
Modulus of Elasticity	DIN 53457	MPa	900 - 1500
Izod Impact Strength*	ASTM D256	KJ/M²	≥ 9.0
Charpy Impact Strength	DIN 53253	KJ/M²	≥ 15
Flexural Strength	DIN 53452	MPa	> 32
Compressive Strength at 10% Deformation	DIN 53421	MPa	> 6.5
Electrical
Surface Resistivity	ASTM D 257	Ω	> 1 x 10¹⁴
Volume Resistivity	ASTM D 257	Ω-cm	> 1 x 10¹⁵
Dielectric Constant at 1 MHZ	ASTM D 150	-	1.56
Dielectric strength	DIN 53481	KV/cm	≥ 90
Thermal
Vicat Softening Temperature	DIN 53460	ºC	≥ 73
Heat Deflection Temperature @ 1.8 MPa	DIN 53461	ºC	58
Coefficient of Linear Expansion	DIN 53752	mm/m ºC	0.08
Thermal Conductivity	DIN 52616	W/m K	0.05 - 0.07Dimensional Tolerances

Dimensional Tolerances

Thickness	Thickness tolerance
	Size 1220*2440mm		Size 1560*3050mm		Size 2050*3050mm
	in mm	absolute in mm	in mm	absolute in mm	in mm	absolute in mm
1mm	-0.9~+1.2	0.2
2mm	±0.2	0.3	±0.2	0.3	±0.2	0.3
3mm	±0.2	0.3	±0.2	0.3	±0.2	0.3
4mm	±0.2	0.4	±0.2	0.4	±0.2	0.4
5mm	±0.2	0.4	±0.2	0.4	±0.2	0.4
6mm	±0.2	0.4

Construction	office and bathroom cabinets, inner and outer decorate panel, commercial decorating shelf, room separating
Transportation	steamboat, airplane, bus, train carriage, roof and carriage inner layer
Advertising	exhibition display, digital printing, silk screen printing, computer lettering, sign board, light box, etc.
Other areas	Chemical anti corrosion project, special cold project, environmental protection

Shandong Huifeng Wood-plastic Profile Co.,Ltd was established in 2013, located in Economic Development Zone Malus heated industrial park. The company is specialized in the development, production of large manufacturers PVC micro-foam board. Product line includes pvc construction template, pvc decoration carving board, pvc advertising board, pvc flooring substrate. All the products use environmentally friendly materials, product quality and stable quality. Microcellular foamed PVC sheet with high surface hardness, deformation, smooth surface characteristics, suitable for furniture, cabinets, bathroom cabinets, toilet partition; advertising printing, logo signs; construction, decoration; cars, trains, ships and other aspects of the interior. Factory covers an area of 140 acres, with a total construction area of 26,000 square meters, now has 16 production lines, with an annual output plate 3 million square meters, 220 million yuan in revenue, profits and taxes 40 million yuan.
