Home > Products > printing machine. > YT Series Four color Flexo Printing Machine
YT Series Four color Flexo Printing Machine
- 100 Set / Sets per Month
- NINGBO
- T/T
You May Like
Product Details
| Condition | New | Plate Type | Other, flexo, Flexible Printing Machine | |
| Place of Origin | Zhejiang, China | Brand Name | RUIHAO | |
| Model Number | YT-4600/4800/41000 | Usage | Paper Printer, Label Printer, Other, Paper Printer, Paper Printer, Label Printer, plastic film printer, aluminum foil printer , nonwoven printer, film printer, Paper Printer,aluminum foil printer , nonwoven printer | |
| Automatic Grade | Automatic | Voltage | 220V/380V | |
| Gross Power | 15KW | Weight | 1T | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
YT Series Four color Flexo Printing Machine is suitable for printing such packing materials as pepp bag, paper , nonwoven, etc.YT Series Four color Flexo Printing Machine
Use:
Performance and characteristic:
1. The operation is simple, the starting is gentle, color printing accurate.
2. Counts Mi Qike to act according to the request hypothesis print quantity, to the number auto-stop, breaks the material auto-stop.
3. Air operated rise and fall printing plate drum, after fluctuation printing ink automatic agitation.
4. The net grain drum passes on the ink, the black color is even.
5. Reliable dry system, coordinate high-speed operation, engine off automatic abruption.
6. 360 degrees continuously adjustable longitudinal to flowered installment.
7. Frequency conversion velocity modulation, adaptation different printing speed.
8. On the version roller seat and receives on material to be loaded with the spot to move and the pause button, is advantageous for when the justification operates the machine.
Main technical parameter
Model | YT-4600 | YT-4800 | YT-41000 |
Max. width of substrate | 600mm | 800mm | 1000mm |
Max. printing width | 560mm | 760mm | 960mm |
Range of printing length | 191to914mm | 191to914mm | 191to914mm |
Max. diameter of web | 450mm | 450mm | 450mm |
Printing speed | 5to50m/min | 5to50m/min | 5to50m/min |
Plate thickness (both-side adhesive tape included) |
2.38mm |
2.38mm |
2.38mm |
Total power | 10.87Kw | 12.5Kw | 14.37Kw |
Machine weight | 3000kg | 3500kg | 4000kg |
