YGD26N1405K Big Power Connector
- shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | hangjie | |
| Model Number | YGD26N1405K | Type | DIN | |
| Application | Power | Gender | Male |
Product Description
Specifications
big power connectorwaterproof power connector
YGD26N1405K big power connector
Features
bayonet coupling, the form of contacts Termination for welding, jack contacts crown spring jacks
Quick Links and separation products, anti-environment, and high reliability.
suitable for high-current power supply series connection.
meet the GJB5371-2005 "circular YGD series power connector universal norms.
Technical characteristics
Operating Temperature: -55 °C ~ 125 °C.
Relative Humidity: 90% to 98%.
Work oppress: 4.39Kpa ~ 101.33Kpa
Salt fog: N, H 48H, R class, B class 96h.
Sealing characterstic:
Jack: differential pressure 1.01 × 103Pa, 1min, no bubbles leakage;
Head mating: 1.8m water depth 48h impermeable.
Vibration: 10Hz ~~ 2000Hz, 196m/s2, short interruptions ≤ 1μs.
Shock: 980m/s2, the short interruptions ≤ 1μs.
Mechanical life: connecting ring material is aluminum alloy ≥ 500, ≥ 2000 connecting ring material is copper alloy.
